Functions
2.1 General
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
49
2.1.4.2 Setting Notes
Specifications
Fault recording (waveform capture) will only take place if address 104 OSC. FAULT REC. is set to Enabled.
Other settings pertaining to fault recording (waveform capture) are found in the Osc. Fault Rec. OSC.
FAULT REC. submenu of the SETTINGS menu. Waveform capture makes a distinction between the trigger
instant for an oscillographic record and the criterion to save the record (address 401 WAVEFORMTRIGGER).
Normally, the trigger is the pickup of a protection element, i.e. the time 0 is defined as the instant the first pro-
tection function picks up. The criterion for saving may be both the device pickup (Save w. Pickup) or the
device trip (Save w. TRIP). A trip command issued by the device can also be used as trigger instant (Start
w. TRIP), in this case it is also the saving criterion.
A fault event starts with the pickup by any protection function and ends with the dropout of the last pickup of a
protection function.
The actual storage time encompasses the pre-fault time PRE. TRIG. TIME (address 404) ahead of the ref-
erence instant, the normal recording time and the post-fault time POST REC. TIME (address 405) after the
storage criterion has reset. The maximum recording duration to each fault (MAX. LENGTH) is entered in
address 403. Recording per fault must not exceed 5 seconds. A total of 8 records can be saved. However, the
total length of time of all fault records in the buffer must not exceed 18 seconds.
An oscillographic record can be triggered by a status change of a binary input, or from a PC via the operator
interface. Storage is then triggered dynamically. The length of the fault recording is set in address 406 BinIn
CAPT.TIME (but not longer than MAX. LENGTH, address 403). Pre-fault and post-fault times will add to this.
If the binary input time is set to ∞, the length of the record equals the time that the binary input is activated
(static), but not longer than the MAX. LENGTH (address 403).
2.1.4.3 Settings
2.1.4.4 Information List
Addr. Parameter Setting Options Default Setting Comments
401 WAVEFORMTRIGGE
R
Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
403 MAX. LENGTH 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
No. Information Type of In-
formation
Comments
- FltRecSta IntSP Fault Recording Start
4 >Trig.Wave.Cap. SP >Trigger Waveform Capture
203 Wave. deleted OUT_Ev Waveform data deleted
30053 Fault rec. run. OUT Fault recording is running
