Siemens SIPROTEC 7SK80 User Manual

Functions
2.15 Temperature Detection via RTD Boxes
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
232
9023 RTD 2 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 2: Temperature Stage 1
Pickup
9024 RTD 2 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 2: Temperature Stage 1
Pickup
9025 RTD 2 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 2: Temperature Stage 2
Pickup
9026 RTD 2 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 2: Temperature Stage 2
Pickup
9031A RTD 3 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 3: Type
9032A RTD 3 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 3: Location
9033 RTD 3 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 3: Temperature Stage 1
Pickup
9034 RTD 3 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 3: Temperature Stage 1
Pickup
9035 RTD 3 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 3: Temperature Stage 2
Pickup
9036 RTD 3 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 3: Temperature Stage 2
Pickup
9041A RTD 4 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 4: Type
9042A RTD 4 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 4: Location
9043 RTD 4 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 4: Temperature Stage 1
Pickup
9044 RTD 4 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 4: Temperature Stage 1
Pickup
9045 RTD 4 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 4: Temperature Stage 2
Pickup
9046 RTD 4 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 4: Temperature Stage 2
Pickup
9051A RTD 5 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 5: Type
Addr. Parameter Setting Options Default Setting Comments
