Technical Data
4.19 User-defined Functions (CFC)
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
389
Configurable in Matrix
Type converter BOOL_TO_DI 5
BUILD_DI 5
DI_TO_BOOL 5
DM_DECODE 8
DINT_TO_REAL 5
DIST_DECODE 8
UINT_TO_REAL 5
REAL_TO_DINT 10
REAL_TO_UINT 10
Comparison COMPARE 12
LOWER_SETPOINT 5
UPPER_SETPOINT 5
LIVE_ZERO 5
ZERO_POINT 5
Metered value COUNTER 6
Time and clock pulse TIMER 5
TIMER_LONG 5
TIMER_SHORT 8
ALARM 21
FLASH 11
Individual Element Number of TICKS
In addition to the defined preassignments, indications and measured values can be freely configured to buff-
ers, preconfigurations can be removed.
