Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
404
Battery
Lithium battery 3 V/1 Ah, type CR 1/2 AA Order No.
VARTA 6127 101 501
Terminals
Voltage terminal block C or block E C53207-A406-D181-1
Voltage terminal block D (inverse print)
1)
C53207-A406-D182-1
Shield for voltage terminal
1)
C53207-A406-D191-1
Current terminal block 4xI C53207-A406-D185-1
Current terminal block 3xI, 1xINs (sensitive) C53207-A406-D186-1
Current terminal short circuit links, 3 pieces C53207-A406-D193-1
Voltage terminal short circuit links, 6 pieces C53207-A406-D194-1
1)
Is the voltage terminal used for internal temperature measurement (7SK805
and 7SK806) additionally the shield for voltage terminal is necessary.
