Siemens SIPROTEC 7SK80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
437
0 P.U. THRESHOLD Flx 15 .. 100 % 20 % Pickup Threshold
0 P.U. THRESHOLD Flx 2.0 .. 260.0 V 110.0 V Pickup Threshold
0 T TRIP DELAY Flx 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY Flx 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0 T PICKUP DELAY Flx 0.00 .. 28800.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY Flx 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLK.by Vol.Loss Flx NO
YES
YES Block in case of Meas.-Voltage
Loss
0A DROPOUT RATIO Flx 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO Flx 1.01 .. 3.00 1.05 Dropout Ratio
0 DO differential Flx 0.02 .. 1.00 Hz 0.03 Hz Dropout differential
201 CT Starpoint P.System Data 1 towards Line
towards Busbar
towards Line CT Starpoint
202 Vnom PRIMARY P.System Data 1 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage
203 Vnom SECONDARY P.System Data 1 34 .. 225 V 100 V Rated Secondary Voltage (L-L)
204 CT PRIMARY P.System Data 1 10 .. 50000 A 400 A CT Rated Primary Current
205 CT SECONDARY P.System Data 1 1A
5A
1A CT Rated Secondary Current
206A Vph / Vdelta P.System Data 1 1.00 .. 3.00 1.73 Matching ratio Phase-VT To
Open-Delta-VT
209 PHASE SEQ. P.System Data 1 A B C
A C B
A B C Phase Sequence
210A TMin TRIP CMD P.System Data 1 0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command Dura-
tion
212 BkrClosed I MIN P.System Data 1 1A 0.04 .. 1.00 A 0.04 A Closed Breaker Min. Current
Threshold
5A 0.20 .. 5.00 A 0.20 A
213 VT Connect. 3ph P.System Data 1 Van, Vbn, Vcn
Vab, Vbc, VGnd
Vab, Vbc
Vab, Vbc, Vx
Van, Vbn, Vcn VT Connection, three-phase
214 Rated Frequency P.System Data 1 50 Hz
60 Hz
50 Hz Rated Frequency
217 Ignd-CT PRIM P.System Data 1 1 .. 50000 A 60 A Ignd-CT rated primary current
218 Ignd-CT SEC P.System Data 1 1A
5A
1A Ignd-CT rated secondary current
220 Threshold BI 1 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 1
221 Threshold BI 2 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 2
222 Threshold BI 3 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 3
223 Threshold BI 4 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 4
224 Threshold BI 5 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 5
225 Threshold BI 6 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 6
226 Threshold BI 7 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 7
232 VXnom PRIMARY P.System Data 1 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage X
233 VXnom SECONDARY P.System Data 1 100 .. 225 V 100 V Rated Secondary Voltage X
235A ATEX100 P.System Data 1 NO
YES
YES Storage of th. Replicas w/o
Power Supply
238 Ignd2-CT PRIM. P.System Data 1 1 .. 50000 A 400 A Ignd2-CT rated primary c. (conn.
to I2)
239 Ignd2-CT SEC. P.System Data 1 1A
5A
1A Ignd2-CT rated secondary
current (I2)
Addr. Parameter Function C Setting Options Default Setting Comments
