Siemens SIPROTEC 7SK80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
440
1304 50N-1 PICKUP 50/51 Overcur. 1A 0.05 .. 35.00 A; ∞ 0.20 A 50N-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
1305 50N-1 DELAY 50/51 Overcur. 0.00 .. 60.00 sec; ∞ 0.50 sec 50N-1 Time Delay
1307 51N PICKUP 50/51 Overcur. 1A 0.05 .. 4.00 A 0.20 A 51N Pickup
5A 0.25 .. 20.00 A 1.00 A
1308 51N TIME DIAL 50/51 Overcur. 0.05 .. 3.20 sec; ∞ 0.20 sec 51N Time Dial
1309 51N TIME DIAL 50/51 Overcur. 0.50 .. 15.00 ; ∞ 5.00 51N Time Dial
1310 51N Drop-out 50/51 Overcur. Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1311 51N IEC CURVE 50/51 Overcur. Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1312 51N ANSI CURVE 50/51 Overcur. Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1313A MANUAL CLOSE 50/51 Overcur. 50N-3 instant.
50N-2 instant.
50N-1 instant.
51N instant.
Inactive
50N-2 instant. Manual Close Mode
1314A 50N-2 active 50/51 Overcur. Always Always 50N-2 active
1315A 50N T DROP-OUT 50/51 Overcur. 0.00 .. 60.00 sec 0.00 sec 50N Drop-Out Time Delay
1316A 50N-3 active 50/51 Overcur. Always Always 50N-3 active
1317 50N-3 PICKUP 50/51 Overcur. 0.25 .. 35.00 A; ∞∞A 50N-3 Pickup
1318 50N-3 DELAY 50/51 Overcur. 0.00 .. 60.00 sec; ∞ 0.05 sec 50N-3 Time Delay
1319A 50N-3 measurem. 50/51 Overcur. Fundamental
True RMS
Instantaneous
Fundamental 50N-3 measurement of
1320A 50N-2 measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 50N-2 measurement of
1321A 50N-1 measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 50N-1 measurement of
1322A 51N measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 51N measurement of
1601 FCT 67N/67N-TOC 67 Direct. O/C OFF
ON
OFF 67N, 67N-TOC Ground Time
Overcurrent
1602 67N-2 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.50 A 67N-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
1603 67N-2 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.10 sec 67N-2 Time Delay
1604 67N-1 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.20 A 67N-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
1605 67N-1 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.50 sec 67N-1 Time Delay
1607 67N-TOC PICKUP 67 Direct. O/C 1A 0.05 .. 4.00 A 0.20 A 67N-TOC Pickup
5A 0.25 .. 20.00 A 1.00 A
1608 67N-TOC T-DIAL 67 Direct. O/C 0.05 .. 3.20 sec; ∞ 0.20 sec 67N-TOC Time Dial
1609 67N-TOC T-DIAL 67 Direct. O/C 0.50 .. 15.00 ; ∞ 5.00 67N-TOC Time Dial
1610 67N-TOC DropOut 67 Direct. O/C Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1611 67N-TOC IEC 67 Direct. O/C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1612 67N-TOC ANSI 67 Direct. O/C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
Addr. Parameter Function C Setting Options Default Setting Comments
