Siemens SIPROTEC 7SK80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
442
2105 67Nc-TOC PICKUP ColdLoadPickup 1A 0.05 .. 4.00 A 1.00 A 67Nc-TOC Pickup
5A 0.25 .. 20.00 A 5.00 A
2106 67Nc-TOC T-DIAL ColdLoadPickup 0.05 .. 3.20 sec; ∞ 0.50 sec 67Nc-TOC Time Dial
2107 67Nc-TOC T-DIAL ColdLoadPickup 0.50 .. 15.00 ; ∞ 5.00 67Nc-TOC Time Dial
2201 INRUSH REST. 50/51 Overcur. OFF
ON
OFF Inrush Restraint
2202 2nd HARMONIC 50/51 Overcur. 10 .. 45 % 15 % 2nd. harmonic in % of fundamen-
tal
2203 CROSS BLOCK 50/51 Overcur. NO
YES
NO Cross Block
2204 CROSS BLK TIMER 50/51 Overcur. 0.00 .. 180.00 sec 0.00 sec Cross Block Time
2205 I Max 50/51 Overcur. 1A 0.30 .. 25.00 A 7.50 A Maximum Current for Inrush Re-
straint
5A 1.50 .. 125.00 A 37.50 A
3101 Sens. Gnd Fault Sens. Gnd Fault OFF
ON
ON with GF log
Alarm Only
OFF (Sensitive) Ground Fault
3102 CT Err. I1 Sens. Gnd Fault 1A 0.001 .. 1.600 A 0.050 A Current I1 for CT Angle Error
5A 0.005 .. 8.000 A 0.250 A
3102 CT Err. I1 Sens. Gnd Fault 1A 0.05 .. 35.00 A 1.00 A Current I1 for CT Angle Error
5A 0.25 .. 175.00 A 5.00 A
3103 CT Err. F1 Sens. Gnd Fault 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I1
3104 CT Err. I2 Sens. Gnd Fault 1A 0.001 .. 1.600 A 1.000 A Current I2 for CT Angle Error
5A 0.005 .. 8.000 A 5.000 A
3104 CT Err. I2 Sens. Gnd Fault 1A 0.05 .. 35.00 A 10.00 A Current I2 for CT Angle Error
5A 0.25 .. 175.00 A 50.00 A
3105 CT Err. F2 Sens. Gnd Fault 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I2
3106 VPH MIN Sens. Gnd Fault 10 .. 100 V 40 V L-Gnd Voltage of Faulted Phase
Vph Min
3107 VPH MAX Sens. Gnd Fault 10 .. 100 V 75 V L-Gnd Voltage of Unfaulted
Phase Vph Max
3109 64-1 VGND Sens. Gnd Fault 1.8 .. 200.0 V; ∞ 40.0 V 64-1 Ground Displacement
Voltage
3110 64-1 VGND Sens. Gnd Fault 10.0 .. 225.0 V; ∞ 70.0 V 64-1 Ground Displacement
Voltage
3111 T-DELAY Pickup Sens. Gnd Fault 0.04 .. 320.00 sec; ∞ 1.00 sec Time-DELAY Pickup
3112 64-1 DELAY Sens. Gnd Fault 0.10 .. 40000.00 sec; ∞ 10.00 sec 64-1 Time Delay
3113 50Ns-2 PICKUP Sens. Gnd Fault 1A 0.001 .. 1.600 A 0.300 A 50Ns-2 Pickup
5A 0.005 .. 8.000 A 1.500 A
3113 50Ns-2 PICKUP Sens. Gnd Fault 1A 0.05 .. 35.00 A 10.00 A 50Ns-2 Pickup
5A 0.25 .. 175.00 A 50.00 A
3114 50Ns-2 DELAY Sens. Gnd Fault 0.00 .. 320.00 sec; ∞ 1.00 sec 50Ns-2 Time Delay
3115 67Ns-2 DIRECT Sens. Gnd Fault Forward
Reverse
Non-Directional
Forward 67Ns-2 Direction
3117 50Ns-1 PICKUP Sens. Gnd Fault 1A 0.001 .. 1.600 A 0.100 A 50Ns-1 Pickup
5A 0.005 .. 8.000 A 0.500 A
3117 50Ns-1 PICKUP Sens. Gnd Fault 1A 0.05 .. 35.00 A 2.00 A 50Ns-1 Pickup
5A 0.25 .. 175.00 A 10.00 A
3118 50Ns-1 DELAY Sens. Gnd Fault 0.00 .. 320.00 sec; ∞ 2.00 sec 50Ns-1 Time delay
3119 51Ns PICKUP Sens. Gnd Fault 1A 0.001 .. 1.400 A 0.100 A 51Ns Pickup
5A 0.005 .. 7.000 A 0.500 A
3119 51Ns PICKUP Sens. Gnd Fault 1A 0.05 .. 4.00 A 1.00 A 51Ns Pickup
5A 0.25 .. 20.00 A 5.00 A
3120 51NsTIME DIAL Sens. Gnd Fault 0.10 .. 4.00 sec; ∞ 1.00 sec 51Ns Time Dial
3121A 50Ns T DROP-OUT Sens. Gnd Fault 0.00 .. 60.00 sec 0.00 sec 50Ns Drop-Out Time Delay
3122 67Ns-1 DIRECT. Sens. Gnd Fault Forward
Reverse
Non-Directional
Forward 67Ns-1 Direction
Addr. Parameter Function C Setting Options Default Setting Comments
