Siemens SIPROTEC 7SK80 User Manual

Appendix
A.8 Settings
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
446
7005 TRIP-Timer 50BF BkrFailure 0.06 .. 60.00 sec; ∞ 0.25 sec TRIP-Timer
7006 50BF PICKUP 50BF BkrFailure 1A 0.05 .. 20.00 A 0.10 A 50BF Pickup current threshold
5A 0.25 .. 100.00 A 0.50 A
7007 50BF PICKUP IE> 50BF BkrFailure 1A 0.05 .. 20.00 A 0.10 A 50BF Pickup earth current
threshold
5A 0.25 .. 100.00 A 0.50 A
8101 MEASURE. SUPERV Measurem.Superv OFF
ON
ON Measurement Supervision
8102 BALANCE V-LIMIT Measurem.Superv 10 .. 100 V 50 V Voltage Threshold for Balance
Monitoring
8103 BAL. FACTOR V Measurem.Superv 0.58 .. 0.90 0.75 Balance Factor for Voltage
Monitor
8104 BALANCE I LIMIT Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Threshold for Balance
Monitoring
5A 0.50 .. 5.00 A 2.50 A
8105 BAL. FACTOR I Measurem.Superv 0.10 .. 0.90 0.50 Balance Factor for Current
Monitor
8106 Σ I THRESHOLD Measurem.Superv 1A 0.05 .. 2.00 A; ∞ 0.10 A Summated Current Monitoring
Threshold
5A 0.25 .. 10.00 A; ∞ 0.50 A
8107 Σ I FACTOR Measurem.Superv 0.00 .. 0.95 0.10 Summated Current Monitoring
Factor
8109 FAST Σ i MONIT Measurem.Superv OFF
ON
ON Fast Summated Current Monitor-
ing
8201 FCT 74TC 74TC TripCirc. ON
OFF
ON 74TC TRIP Circuit Supervision
8202 Alarm Delay 74TC TripCirc. 1 .. 30 sec 2 sec Delay Time for alarm
8301 DMD Interval Demand meter 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
8302 DMD Sync.Time Demand meter On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
8311 MinMax cycRESET Min/Max meter NO
YES
YES Automatic Cyclic Reset Function
8312 MiMa RESET TIME Min/Max meter 0 .. 1439 min 0 min MinMax Reset Timer
8313 MiMa RESETCYCLE Min/Max meter 1 .. 365 Days 7 Days MinMax Reset Cycle Period
8314 MinMaxRES.START Min/Max meter 1 .. 365 Days 1 Days MinMax Start Reset Cycle in
8315 MeterResolution Energy Standard
Factor 10
Factor 100
Standard Meter resolution
9000 UDP Port RTD-Box 0 .. 65535 5000 UDP service port in the RTD box
9001 IP address[0] RTD-Box 0 .. 255 0 IP address[0] of RTD box,
connec. by UDP
9002 IP address[1] RTD-Box 0 .. 255 0 IP address[1] of RTD box,
connec. by UDP
9003 IP address[2] RTD-Box 0 .. 255 0 IP address[2] of RTD box,
connec. by UDP
9004 IP address[3] RTD-Box 0 .. 255 0 IP address[3] of RTD box,
connec. by UDP
9005 UDP Port RTD-Box 0 .. 65535 5000 UDP service port in the RTD box
9006 IP address[0] RTD-Box 0 .. 255 0 IP address[0] of RTD box,
connec. by UDP
9007 IP address[1] RTD-Box 0 .. 255 0 IP address[1] of RTD box,
connec. by UDP
9008 IP address[2] RTD-Box 0 .. 255 0 IP address[2] of RTD box,
connec. by UDP
9009 IP address[3] RTD-Box 0 .. 255 0 IP address[3] of RTD box,
connec. by UDP
Addr. Parameter Function C Setting Options Default Setting Comments
