Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
453
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO 135 51 1 Yes
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group SP * * * LED BI BO 135 52 1 Yes
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP On
Off
**LEDBO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP On
Off
**LEDBO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP On
Off
**LEDBO
15 >Test mode (>Test mode) Device, General SP * * * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device, General SP * * * LED BI BO 135 54 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device, General OUT On
Off
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device, General IntSP On
Off
* * LED BO 160 18 1 Yes
55 Reset Device (Reset Device) Device, General OUT on * * 160 4 1 No
56 Initial Start of Device (Initial Start) Device, General OUT on * * LED BO 160 5 1 No
67 Resume (Resume) Device, General OUT on * * LED BO
68 Clock Synchronization Error
(Clock SyncError)
Device, General OUT On
Off
**LEDBO
69 Daylight Saving Time (DayLight-
SavTime)
Device, General OUT On
Off
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device, General OUT On
Off
* * LED BO 160 22 1 Yes
71 Settings Check (Settings Check) Device, General OUT * * * LED BO
72 Level-2 change (Level-2 change) Device, General OUT On
Off
**LEDBO
73 Local setting change (Local
change)
Device, General OUT * * *
110 Event lost (Event Lost) Device, General OUT_
Ev
on * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Device, General OUT on * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device, General OUT On
Off
* * LED BO 135 145 1 Yes
126 Protection ON/OFF (via system
port) (ProtON/OFF)
P.System Data 2 IntSP On
Off
**LEDBO
140 Error with a summary alarm
(Error Sum Alarm)
Device, General OUT On
Off
* * LED BO 160 47 1 Yes
160 Alarm Summary Event (Alarm
Sum Event)
Device, General OUT On
Off
* * LED BO 160 46 1 Yes
161 Failure: General Current Supervi-
sion (Fail I Superv.)
Measurem.Superv OUT On
Off
* * LED BO 160 32 1 Yes
162 Failure: Current Summation (Fail-
ure Σ I)
Measurem.Superv OUT On
Off
* * LED BO 135 182 1 Yes
163 Failure: Current Balance (Fail I
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 183 1 Yes
167 Failure: Voltage Balance (Fail V
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 186 1 Yes
169 VT Fuse Failure (alarm >10s) (VT
FuseFail>10s)
Measurem.Superv OUT On
Off
* * LED BO 135 188 1 Yes
170 VT Fuse Failure (alarm instanta-
neous) (VT FuseFail)
Measurem.Superv OUT On
Off
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
