Siemens SIPROTEC 7SK80 User Manual

Appendix
A.9 Information List
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
460
1843 Cross blk: PhX blocked PhY
(INRUSH X-BLK)
50/51 Overcur. OUT * On
Off
* LED BO 60 104 2 Yes
1851 50-1 BLOCKED (50-1
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 105 1 Yes
1852 50-2 BLOCKED (50-2
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 106 1 Yes
1853 50N-1 BLOCKED (50N-1
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 107 1 Yes
1854 50N-2 BLOCKED (50N-2
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 108 1 Yes
1855 51 BLOCKED (51 BLOCKED) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 109 1 Yes
1856 51N BLOCKED (51N BLOCKED) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 110 1 Yes
1866 51 Disk emulation Pickup (51
Disk Pickup)
50/51 Overcur. OUT * * * LED BO
1867 51N Disk emulation picked up
(51N Disk Pickup)
50/51 Overcur. OUT * * * LED BO
1994 Cold-Load-Pickup switched OFF
(CLP OFF)
ColdLoadPickup OUT On
Off
* * LED BO 60 244 1 Yes
1995 Cold-Load-Pickup is BLOCKED
(CLP BLOCKED)
ColdLoadPickup OUT On
Off
On
Off
* LED BO 60 245 1 Yes
1996 Cold-Load-Pickup is RUNNING
(CLP running)
ColdLoadPickup OUT On
Off
* * LED BO 60 246 1 Yes
1997 Dynamic settings are ACTIVE
(Dyn set. ACTIVE)
ColdLoadPickup OUT On
Off
* * LED BO 60 247 1 Yes
2614 >BLOCK 67N/67N-TOC (>BLK
67N/67NTOC)
67 Direct. O/C SP * * * LED BI BO
2616 >BLOCK 67N-2 (>BLOCK 67N-2) 67 Direct. O/C SP * * * LED BI BO 63 74 1 Yes
2623 >BLOCK 67N-1 (>BLOCK 67N-1) 67 Direct. O/C SP * * * LED BI BO 63 3 1 Yes
2624 >BLOCK 67N-TOC (>BLOCK
67N-TOC)
67 Direct. O/C SP * * * LED BI BO 63 4 1 Yes
2635 Ground forward (Ground forward) 67 Direct. O/C OUT on * * LED BO 63 87 1 Yes
2636 Ground reverse (Ground reverse) 67 Direct. O/C OUT on * * LED BO 63 88 1 Yes
2646 67N-2 picked up (67N-2 picked
up)
67 Direct. O/C OUT * On
Off
* LED BO 63 62 2 Yes
2648 67N-2 Time Out (67N-2 Time
Out)
67 Direct. O/C OUT * * * LED BO 63 63 2 Yes
2656 67N/67N-TOC switched OFF
(67N OFF)
67 Direct. O/C OUT On
Off
**LEDBO63131Yes
2657 67N/67N-TOC is BLOCKED
(67N BLOCKED)
67 Direct. O/C OUT On
Off
On
Off
* LED BO 63 14 1 Yes
2658 67N/67N-TOC is ACTIVE (67N
ACTIVE)
67 Direct. O/C OUT On
Off
**LEDBO63151Yes
2659 67N-1 is BLOCKED (67N-1
BLOCKED)
67 Direct. O/C OUT On
Off
On
Off
* LED BO 63 93 1 Yes
2668 67N-2 is BLOCKED (67N-2
BLOCKED)
67 Direct. O/C OUT On
Off
On
Off
* LED BO 63 94 1 Yes
2677 67N-TOC is BLOCKED (67N-
TOC BLOCKED)
67 Direct. O/C OUT On
Off
On
Off
* LED BO 63 96 1 Yes
2679 67N-2 TRIP (67N-2 TRIP) 67 Direct. O/C OUT * on m LED BO 63 64 2 Yes
2681 67N-1 picked up (67N-1 picked
up)
67 Direct. O/C OUT * On
Off
* LED BO 63 41 2 Yes
2682 67N-1 Time Out (67N-1 Time
Out)
67 Direct. O/C OUT * * * LED BO 63 42 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
