2.2 Differential Protection
137
7UT613/63x Manual
C53000-G1176-C160-2
5684 Diff>> L1 OUT Diff. prot: IDIFF>> L1 (without Tdelay)
5685 Diff>> L2 OUT Diff. prot: IDIFF>> L2 (without Tdelay)
5686 Diff>> L3 OUT Diff. prot: IDIFF>> L3 (without Tdelay)
5691 Diff> TRIP OUT Differential prot.: TRIP by IDIFF>
5692 Diff>> TRIP OUT Differential prot.: TRIP by IDIFF>>
5701 Diff L1: VI Diff. curr. in L1 at trip without Tdelay
5702 Diff L2: VI Diff. curr. in L2 at trip without Tdelay
5703 Diff L3: VI Diff. curr. in L3 at trip without Tdelay
5704 Res. L1: VI Restr.curr. in L1 at trip without Tdelay
5705 Res. L2: VI Restr.curr. in L2 at trip without Tdelay
5706 Res. L3: VI Restr.curr. in L3 at trip without Tdelay
5721 Diff CT-I1: VI Diff. prot: Adaption factor CT I1
5722 Diff CT-I2: VI Diff. prot: Adaption factor CT I2
5723 Diff CT-I3: VI Diff. prot: Adaption factor CT I3
5724 Diff CT-I4: VI Diff. prot: Adaption factor CT I4
5725 Diff CT-I5: VI Diff. prot: Adaption factor CT I5
5726 Diff CT-I6: VI Diff. prot: Adaption factor CT I6
5727 Diff CT-I7: VI Diff. prot: Adaption factor CT I7
5728 Diff CT-I8: VI Diff. prot: Adaption factor CT I8
5729 Diff CT-I9: VI Diff. prot: Adaption factor CT I9
5730 DiffCT-I10: VI Diff. prot: Adaption factor CT I10
5731 DiffCT-I11: VI Diff. prot: Adaption factor CT I11
5732 DiffCT-I12: VI Diff. prot: Adaption factor CT I12
5733 Diff CT-M1: VI Diff. prot: Adaption factor CT M1
5734 Diff CT-M2: VI Diff. prot: Adaption factor CT M2
5735 Diff CT-M3: VI Diff. prot: Adaption factor CT M3
5736 Diff CT-M4: VI Diff. prot: Adaption factor CT M4
5737 Diff CT-M5: VI Diff. prot: Adaption factor CT M5
5738 Diff CT-IX1: VI Diff. prot: Adaption factor aux. CT IX1
5739 Diff CT-IX2: VI Diff. prot: Adaption factor aux. CT IX2
5740 Diff CT-IX3: VI Diff. prot: Adaption factor aux. CT IX3
5741 Diff CT-IX4: VI Diff. prot: Adaption factor aux. CT IX4
5742 Diff DC L1 OUT Diff: DC L1
5743 Diff DC L2 OUT Diff: DC L2
5744 Diff DC L3 OUT Diff: DC L3
5745 Diff DC InCha OUT Diff: Increase of char. phase (DC)
No. Information Type of In-
formation
Comments
