A Appendix
582
7UT613/63x Manual
C53000-G1176-C160-2
A.9 Information List
Indications for IEC 60 870-5-103 are always reported ON / OFF if they are subject to
general interrogation for IEC 60 870-5-103. If not, they are reported only as ON.
New user-defined indications or such newly allocated to IEC 60 870-5-103 are set to
ON / OFF and subjected to general interrogation if the information type is not a spon-
taneous event („.._Ev“). Further information on messages can be found in detail in the
SIPROTEC
®
4 System Description, Order No. E50417-H1100-C151.
In columns „Event Log“, „Trip Log“ and „Ground Fault Log“ the following applies:
UPPER CASE NOTATION “ON/OFF”: definitely set, not allocatable
lower case notation “on/off”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
In column „Marked in Oscill.Record“ the following applies:
UPPER CASE NOTATION “M”: definitely set, not allocatable
lower case notation “m”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
- Reset LED (Reset LED) Device IntSP ON * * LED BO 176 19 1 No
- Test mode (Test mode) Device IntSP ON
OFF
* * LED BO 176 21 1 Yes
- Stop data transmission (DataS-
top)
Device IntSP ON
OFF
* * LED BO 176 20 1 Yes
- Unlock data transmission via BI
(UnlockDT)
Device IntSP * * * LED BO
- >Back Light on (>Light on) Device SP ON
OFF
**LEDBIBO
- Clock Synchronization (Synch-
Clock)
Device IntSP
_Ev
* * * LED BO
- Hardware Test Mode (HWTest-
Mod)
Device IntSP ON
OFF
**LEDBO
- Group A (Group A) Change Group IntSP ON
OFF
* * LED BO 176 23 1 Yes
- Group B (Group B) Change Group IntSP ON
OFF
* * LED BO 176 24 1 Yes
- Group C (Group C) Change Group IntSP ON
OFF
* * LED BO 176 25 1 Yes
- Group D (Group D) Change Group IntSP ON
OFF
* * LED BO 176 26 1 Yes
- Fault Recording Start (FltRecSta) Osc. Fault Rec. IntSP ON
OFF
*mLEDBO
- >Quitt Lock Out: General Trip
(>QuitG-TRP)
P.System Data 2 IntSP * * * LED BI FC
TN
BO
