2.4 Time Overcurrent Protection for Phase and Residual Currents
171
7UT613/63x Manual
C53000-G1176-C160-2
2.4.2.3 Information List
2121 Ip 1
A
0.10 .. 4.00 A 4.00 A Ip Pickup
5
A
0.50 .. 20.00 A 20.00 A
2122 Ip 0.10 .. 4.00 I/InS 4.00 I/InS Ip Pickup
2123 T Ip 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
2124 D Ip 0.50 .. 15.00 ; ∞ 5.00 D Ip Time Dial
No. Information Type of In-
formation
Comments
023.2404 >BLK Phase O/C SP >BLOCK Phase time overcurrent
023.2411 O/C Phase OFF OUT Time Overcurrent Phase is OFF
023.2412 O/C Phase BLK OUT Time Overcurrent Phase is BLOCKED
023.2413 O/C Phase ACT OUT Time Overcurrent Phase is ACTIVE
023.2422 O/C Ph L1 PU OUT Time Overcurrent Phase L1 picked up
023.2423 O/C Ph L2 PU OUT Time Overcurrent Phase L2 picked up
023.2424 O/C Ph L3 PU OUT Time Overcurrent Phase L3 picked up
023.2491 O/C Ph. Not av. OUT O/C Phase: Not available for this object
023.2501 >BLK Ph.O/C Inr SP >BLOCK time overcurrent Phase InRush
023.2502 >BLOCK I>> SP >BLOCK I>>
023.2503 >BLOCK I> SP >BLOCK I>
023.2504 >BLOCK Ip SP >BLOCK Ip
023.2514 I>> BLOCKED OUT I>> BLOCKED
023.2515 I> BLOCKED OUT I> BLOCKED
023.2516 Ip BLOCKED OUT Ip BLOCKED
023.2521 I>> picked up OUT I>> picked up
023.2522 I> picked up OUT I> picked up
023.2523 Ip picked up OUT Ip picked up
023.2524 I> InRush PU OUT I> InRush picked up
023.2525 Ip InRush PU OUT Ip InRush picked up
023.2526 L1 InRush PU OUT Phase L1 InRush picked up
023.2527 L2 InRush PU OUT Phase L2 InRush picked up
023.2528 L3 InRush PU OUT Phase L3 InRush picked up
023.2531 L1 InRush det. OUT Phase L1 InRush detected
023.2532 L2 InRush det. OUT Phase L2 InRush detected
023.2533 L3 InRush det. OUT Phase L3 InRush detected
023.2534 INRUSH X-BLK OUT Cross blk: PhX blocked PhY
023.2541 I>> Time Out OUT I>> Time Out
023.2542 I> Time Out OUT I> Time Out
023.2543 Ip Time Out OUT Ip Time Out
023.2551 I>> TRIP OUT I>> TRIP
023.2552 I> TRIP OUT I> TRIP
023.2553 Ip TRIP OUT Ip TRIP
Addr. Parameter C Setting Options Default Setting Comments
