A.11 Measured Values
617
7UT613/63x Manual
C53000-G1176-C160-2
A.11 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Control DIGSI (CntrlDIGSI) Cntrl Authority - - - - - CD DD
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CD DD
044.2611 Temperat. rise for warning and trip (Θ/Θtrip
=)
Meas. Thermal - - - - - CFC CD DD
044.2612 Temperature rise for phase L1 (Θ/ΘtripL1=) Meas. Thermal - - - - - CFC CD DD
044.2613 Temperature rise for phase L2 (Θ/ΘtripL2=) Meas. Thermal - - - - - CFC CD DD
044.2614 Temperature rise for phase L3 (Θ/ΘtripL3=) Meas. Thermal - - - - - CFC CD DD
044.2615 Hot spot temperature of leg L1 (Θ leg L1=) Meas. Thermal - - - - - CFC CD DD
044.2616 Hot spot temperature of leg L2 (Θ leg L2=) Meas. Thermal - - - - - CFC CD DD
044.2617 Hot spot temperature of leg L3 (Θ leg L3=) Meas. Thermal - - - - - CFC CD DD
044.2618 Hot spot temperature of leg L12 (Θ leg L12=) Meas. Thermal - - - - - CFC CD DD
044.2619 Hot spot temperature of leg L23 (Θ leg L23=) Meas. Thermal - - - - - CFC CD DD
044.2620 Hot spot temperature of leg L31 (Θ leg L31=) Meas. Thermal - - - - - CFC CD DD
044.2621 Aging Rate (Ag.Rate=) Meas. Thermal - - - - - CFC CD DD
044.2622 Load Reserve to warning level (ResWARN=) Meas. Thermal - - - - - CFC CD DD
044.2623 Load Reserve to alarm level (ResALARM=) Meas. Thermal - - - - - CFC CD DD
199.2640 Idiff REF (I/Inominal object [%]) (IdiffREF=) Meas. Dif/Rest. - - - - - CFC CD DD
199.2641 Irest REF (I/Inominal object [%]) (IrestREF=) Meas. Dif/Rest. - - - - - CFC CD DD
204.2611 O/L2 Temperat. rise for warning and trip
(2Θ/Θtrip =)
Meas. Thermal - - - - - CFC CD DD
204.2612 Th. O/L 2 Temperature rise for phase L1
(2Θ/ΘtrpL1=)
Meas. Thermal - - - - - CFC CD DD
204.2613 Th. O/L 2 Temperature rise for phase L2
(2Θ/ΘtrpL2=)
Meas. Thermal - - - - - CFC CD DD
204.2614 Th. O/L 2 Temperature rise for phase L3
(2Θ/ΘtrpL3=)
Meas. Thermal - - - - - CFC CD DD
204.2615 Th. O/L 2 Hot spot temperature of leg L1 (2Θ
leg L1=)
Meas. Thermal - - - - - CFC CD DD
204.2616 Th. O/L 2 Hot spot temperature of leg L2 (2Θ
leg L2=)
Meas. Thermal - - - - - CFC CD DD
204.2617 Th. O/L 2 Hot spot temperature of leg L3 (2Θ
leg L3=)
Meas. Thermal - - - - - CFC CD DD
204.2618 Th. O/L2 Hot spot temperature of leg L12 (2Θ
legL12=)
Meas. Thermal - - - - - CFC CD DD
204.2619 Th. O/L2 Hot spot temperature of leg L23 (2Θ
legL23=)
Meas. Thermal - - - - - CFC CD DD
204.2620 Th. O/L2 Hot spot temperature of leg L31 (2Θ
legL31=)
Meas. Thermal - - - - - CFC CD DD
204.2621 Thermal Overload 2 Aging Rate (Ag.Rate2=) Meas. Thermal - - - - - CFC CD DD
204.2622 Th. O/L 2 Load Reserve to warning level
(ResWARN2=)
Meas. Thermal - - - - - CFC CD DD
204.2623 Th. O/L 2 Load Reserve to alarm level
(ResALARM2=)
Meas. Thermal - - - - - CFC CD DD
205.2640 Idiff REF2 (I/Inominal object [%]) (IdiffRE2=) Meas. Dif/Rest. - - - - - CFC CD DD
205.2641 Irest REF2 (I/Inominal object [%])
(IrestRE2=)
Meas. Dif/Rest. - - - - - CFC CD DD
328.2711 Minimum Value $00 ($00min=) addMV - - - - - CFC CD DD
328.2712 Maximum value $00 ($00max=) addMV - - - - - CFC CD DD
328.2713 long term average value $00 ($00ave=) addMV - - - - - CFC CD DD
