A Appendix
618
7UT613/63x Manual
C53000-G1176-C160-2
328.2714 Min. of average value $00 ($00amin=) addMV - - - - - CFC CD DD
328.2715 Max. of average value $00 ($00amax=) addMV - - - - - CFC CD DD
621 U L1-E (UL1E=) Measurement - - - - - CFC CD DD
622 U L2-E (UL2E=) Measurement - - - - - CFC CD DD
623 U L3-E (UL3E=) Measurement - - - - - CFC CD DD
624 U L12 (UL12=) Measurement - - - - - CFC CD DD
625 U L23 (UL23=) Measurement - - - - - CFC CD DD
626 U L31 (UL31=) Measurement - - - - - CFC CD DD
627 Displacement voltage UE (UE =) Measurement - - - - - CFC CD DD
629 U1 (positive sequence) (U1 =) Measurement - - - - - CFC CD DD
630 U2 (negative sequence) (U2 =) Measurement - - - - - CFC CD DD
641 P (active power) (P =) Measurement - - - - - CFC CD DD
642 Q (reactive power) (Q =) Measurement - - - - - CFC CD DD
644 Frequency (Freq=) Measurement - - - - - CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
721 Operat. meas. current IL1 side 1 (IL1S1=) Measurement 134 139 No 9 1 CFC CD DD
722 Operat. meas. current IL2 side 1 (IL2S1=) Measurement 134 139 No 9 5 CFC CD DD
723 Operat. meas. current IL3 side 1 (IL3S1=) Measurement 134 139 No 9 3 CFC CD DD
724 Operat. meas. current IL1 side 2 (IL1S2=) Measurement 134 139 No 9 2 CFC CD DD
725 Operat. meas. current IL2 side 2 (IL2S2=) Measurement 134 139 No 9 6 CFC CD DD
726 Operat. meas. current IL3 side 2 (IL3S2=) Measurement 134 139 No 9 4 CFC CD DD
727 Operat. meas. current IL1 side 3 (IL1S3=) Measurement - - - - - CFC CD DD
728 Operat. meas. current IL2 side 3 (IL2S3=) Measurement - - - - - CFC CD DD
729 Operat. meas. current IL3 side 3 (IL3S3=) Measurement - - - - - CFC CD DD
765 (U/Un) / (f/fn) (U/f =) Measurement - - - - - CFC CD DD
766 Calculated temperature (U/f) (U/f th. =) Meas. Thermal - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)=) Energy 133 55 No 205 - CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)=) Energy 133 56 No 205 - CD DD
901 Power Factor (PF =) Measurement - - - - - CFC CD DD
910 Calculated rotor temp. (unbal. load) (Therm-
Rep.=)
Meas. Thermal - - - - - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Meas. Thermal 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Meas. Thermal 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Meas. Thermal 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Meas. Thermal 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Meas. Thermal 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Meas. Thermal 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Meas. Thermal 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Meas. Thermal 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Meas. Thermal 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10 =) Meas. Thermal 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11 =) Meas. Thermal 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12 =) Meas. Thermal 134 146 No 9 12 CFC CD DD
7742 IDiffL1(I/Inominal object [%]) (IDiffL1=) Meas. Dif/Rest. - - - - - CFC CD DD
7743 IDiffL2(I/Inominal object [%]) (IDiffL2=) Meas. Dif/Rest. - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
