2 Functions
312
7UT613/63x Manual
C53000-G1176-C160-2
2.22.4 Differential and Restraining Measured Values
Depending on its configuration, the device calculates the measured values that are
specific to differential protection.
2.22.4.1 Function Description
The differential and restraining values of the differential protection and the restricted
earth fault protection are listed in table 2-16. They always refer to the nominal current
of the main protected object, which results from the parameterised nominal data of the
main protected object (subsection 2.1.5). For multi-winding transformers with different
winding ratings, the most powerful winding is decisive, for busbars and lines the
nominal operation current as set for the protected object. In case of 1-phase busbar
protection, only the values of the connected and declared phase are displayed.
In case of restricted earth fault protection, the nominal phase currents provide the ref-
erence value.
204.2612 2Θ/ΘtrpL1= MV Th. O/L 2 Temperature rise for phase L1
204.2613 2Θ/ΘtrpL2= MV Th. O/L 2 Temperature rise for phase L2
204.2614 2Θ/ΘtrpL3= MV Th. O/L 2 Temperature rise for phase L3
204.2615 2Θ leg L1= MV Th. O/L 2 Hot spot temperature of leg L1
204.2616 2Θ leg L2= MV Th. O/L 2 Hot spot temperature of leg L2
204.2617 2Θ leg L3= MV Th. O/L 2 Hot spot temperature of leg L3
204.2618 2Θ legL12= MV Th. O/L2 Hot spot temperature of leg L12
204.2619 2Θ legL23= MV Th. O/L2 Hot spot temperature of leg L23
204.2620 2Θ legL31= MV Th. O/L2 Hot spot temperature of leg L31
204.2621 Ag.Rate2= MV Thermal Overload 2 Aging Rate
204.2622 ResWARN2= MV Th. O/L 2 Load Reserve to warning level
204.2623 ResALARM2= MV Th. O/L 2 Load Reserve to alarm level
766 U/f th. = MV Calculated temperature (U/f)
910 ThermRep.= MV Calculated rotor temp. (unbal. load)
1068 Θ RTD 1 = MV Temperature of RTD 1
1069 Θ RTD 2 = MV Temperature of RTD 2
1070 Θ RTD 3 = MV Temperature of RTD 3
1071 Θ RTD 4 = MV Temperature of RTD 4
1072 Θ RTD 5 = MV Temperature of RTD 5
1073 Θ RTD 6 = MV Temperature of RTD 6
1074 Θ RTD 7 = MV Temperature of RTD 7
1075 Θ RTD 8 = MV Temperature of RTD 8
1076 Θ RTD 9 = MV Temperature of RTD 9
1077 Θ RTD10 = MV Temperature of RTD10
1078 Θ RTD11 = MV Temperature of RTD11
1079 Θ RTD12 = MV Temperature of RTD12
No. Information Type of In-
formation
Comments
