4.1 General
425
7UT613/63x Manual
C53000-G1176-C160-2
4.1.5 Communications Interfaces
Operator Interface
Service/Modem Interface
Connection Front side, non-isolated, RS232,
9-pin D-subminiature female connector for connection of a PC
computers
Operation With DIGSI
Transmission
speed
min. 4,800 Baud; max. 115,200 Baud;
factory setting: 115,200 Baud; parity: 8E1
Maximum bridgeable dis-
tance
15 m
RS232
RS485
FOC
acc. to ordered version
isolated interface for data transfer
for operation using DIGSI or
for connection of a RTD box
RS232 Connection for flush-mounted
housing
rear panel, mounting location
„C“,
9-pole DSUB port
shielded data cable
Connector for surface mounted
housing
in inclined housing on the
case bottom;
shielded data cable
Test Voltage 500 V; 50 Hz
Transmission speed min. 4 800 Bd,
max. 115 200 Bd;
Factory 38 400 Baud
Maximum bridgeable
distance
15 m
RS485 Connection for flush-mounted
housing
rear panel, mounting location
„C“,
9-pole DSUB port
shielded data cable
Connector for surface mounted
housing
in inclined housing on the
case bottom;
shielded data cable
Test Voltage 500 V; 50 Hz
Transmission speed min. 4 800 Baud; max. 115 200
Baud;
Factory 38 400 Baud
Maximum bridgeable
distance
1,000 m
