Siemens SIPROTEC 7UT613 series User Manual

4 Technical Data
426
7UT613/63x Manual
C53000-G1176-C160-2
System Interface (optional)
Fibre optic cable (FO) FOC connector type ST connector
Connection for flush-mounted
housing
rear panel, mounting location
„C“
Connector for surface mounted
housing
in the inclined housing on the
case bottom
optical wavelength λ = 820 nm
Laser class 1 according to
EN 60825-1/-2
Using glass fibre 50/125 µm or
using glass fibre 62.5/125 µm
^Permissible optical signal at-
tenuation
Max. 8 dB, with glass fibre
62.5/125 µm
Maximum transmission dis-
tance
max. 1.5 km (0.94 miles)
Character Idle State Configurable; factory setting
„Light off“
IEC 60870-5-103
RS232
RS485
FOC
Profibus RS485
Profibus FOC
acc. to ordered version
Isolated interface for data transfer to a master terminal
IEC 60870-5-103
different isolated-neutral versions available
RS232
rear panel, mounting loca-
tion „B“,
9-pole DSUB miniature
socket
Connection for flush-mounted housing
Connection for surface
mounted case
in the inclined housing on the
case bottom
Test voltage 500 V; 50 Hz
Transmission speed min. 300 Bd, max. 57,600 Bd
factory setting 9,600 Bd
Maximum bridgeable
distance
15 m (50 ft)
RS485
rear panel, mounting loca-
tion „B“,
9-pole DSUB miniature
socket
Connection for flush-mounted housing
Connection for surface
mounted case
in the inclined housing on the
case bottom
Test voltage 500 V; 50 Hz
Transmission speed min.300 Bd, max. 57,600 Bd
factory setting 9,600 Bd
Maximum bridgeable
distance
1 km
