Siemens SIPROTEC 7UT613 series User Manual

2.9 Thermal Overload Protection
231
7UT613/63x Manual
C53000-G1176-C160-2
2.9.7 Information List
No. Information Type of In-
formation
Comments
044.2404 >BLK ThOverload SP >BLOCK Thermal Overload Protection
044.2411 Th.Overload OFF OUT Thermal Overload Protection OFF
044.2412 Th.Overload BLK OUT Thermal Overload Protection BLOCKED
044.2413 Th.Overload ACT OUT Thermal Overload Protection ACTIVE
044.2421 O/L Th. pick.up OUT Thermal Overload picked up
044.2451 ThOverload TRIP OUT Thermal Overload TRIP
044.2491 O/L Not avail. OUT Th. Overload Not available for this obj.
044.2494 O/L Adap.fact. OUT Th. Overload err.:adverse Adap.factor CT
044.2601 >Emer.Start O/L SP >Emergency start Th. Overload Protection
044.2602 O/L I Alarm OUT Th. Overload Current Alarm (I alarm)
044.2603 O/L Θ Alarm OUT Thermal Overload Alarm
044.2604 O/L ht.spot Al. OUT Thermal Overload hot spot Th. Alarm
044.2605 O/L h.spot TRIP OUT Thermal Overload hot spot Th. TRIP
044.2606 O/L ag.rate Al. OUT Thermal Overload aging rate Alarm
044.2607 O/L ag.rt. TRIP OUT Thermal Overload aging rate TRIP
044.2609 O/L No Th.meas. OUT Th. Overload No temperature measured
