Siemens SIPROTEC 7UT613 series User Manual

2.7 Single-Phase Time Overcurrent Protection
205
7UT613/63x Manual
C53000-G1176-C160-2
Note
In the following parameter overview the addresses 2703 and 2706 apply to a high-
sensitive current measuring input and are independent from the rated current.
2.7.5 Settings
The table indicates region-specific presettings. Column C (configuration) indicates the
corresponding secondary nominal current of the current transformer.
2.7.6 Information List
Addr. Parameter C Setting Options Default Setting Comments
2701 1Phase O/C OFF
ON
Block relay
OFF 1Phase Time Overcurrent
2702 1Phase I>> 1A 0.05 .. 35.00 A; ∞ 0.50 A 1Phase O/C I>> Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
2703 1Phase I>> 0.003 .. 1.500 A; ∞ 0.300 A 1Phase O/C I>> Pickup
2704 T 1Phase I>> 0.00 .. 60.00 sec; ∞ 0.10 sec T 1Phase O/C I>> Time Delay
2705 1Phase I> 1A 0.05 .. 35.00 A; ∞ 0.20 A 1Phase O/C I> Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
2706 1Phase I> 0.003 .. 1.500 A; ∞ 0.100 A 1Phase O/C I> Pickup
2707 T 1Phase I> 0.00 .. 60.00 sec; ∞ 0.50 sec T 1Phase O/C I> Time Delay
No. Information Type of In-
formation
Comments
200.2404 >BLK 1Ph. O/C SP >BLOCK Time Overcurrent 1Phase
200.2411 O/C 1Ph. OFF OUT Time Overcurrent 1Phase is OFF
200.2412 O/C 1Ph. BLK OUT Time Overcurrent 1Phase is BLOCKED
200.2413 O/C 1Ph. ACT OUT Time Overcurrent 1Phase is ACTIVE
200.2421 O/C 1Ph PU OUT Time Overcurrent 1Phase picked up
200.2451 O/C 1Ph TRIP OUT Time Overcurrent 1Phase TRIP
200.2492 O/C 1Ph Err CT OUT O/C 1Phase err.:No auxiliary CT assigned
200.2502 >BLK 1Ph. I>> SP >BLOCK Time Overcurrent 1Ph. I>>
200.2503 >BLK 1Ph. I> SP >BLOCK Time Overcurrent 1Ph. I>
200.2514 O/C 1Ph I>> BLK OUT Time Overcurrent 1Phase I>> BLOCKED
200.2515 O/C 1Ph I> BLK OUT Time Overcurrent 1Phase I> BLOCKED
200.2521 O/C 1Ph I>> PU OUT Time Overcurrent 1Phase I>> picked up
200.2522 O/C 1Ph I> PU OUT Time Overcurrent 1Phase I> picked up
200.2551 O/C1Ph I>> TRIP OUT Time Overcurrent 1Phase I>> TRIP
200.2552 O/C 1Ph I> TRIP OUT Time Overcurrent 1Phase I> TRIP
200.2561 O/C 1Ph I: VI Time Overcurrent 1Phase: I at pick up
