Siemens SIPROTEC 7UT613 series User Manual

2 Functions
136
7UT613/63x Manual
C53000-G1176-C160-2
2.2.9 Information List
1271 2. HARMONIC 10 .. 80 % 15 % 2nd Harmonic Content in I-DIFF
1272A CROSSB. 2. HARM 2 .. 1000 Cycle; 0; ∞ 3 Cycle Time for Cross-blocking 2nd Harm.
1276 n. HARMONIC 10 .. 80 % 30 % n-th Harmonic Content in I-DIFF
1277A CROSSB. n.HARM 2 .. 1000 Cycle; 0; ∞ 0 Cycle Time for Cross-blocking n-th Harm.
1278A IDIFFmax n.HM 0.5 .. 20.0 I/InO 1.5 I/InO Limit IDIFFmax of n-th Harm.Restraint
1281 I-DIFF> MON. 0.15 .. 0.80 I/InO 0.20 I/InO Pickup Value of diff. Current Monitoring
1282 T I-DIFF> MON. 1 .. 10 sec 2 sec T I-DIFF> Monitoring Time Delay
No. Information Type of In-
formation
Comments
5603 >Diff BLOCK SP >BLOCK differential protection
5615 Diff OFF OUT Differential protection is switched OFF
5616 Diff BLOCKED OUT Differential protection is BLOCKED
5617 Diff ACTIVE OUT Differential protection is ACTIVE
5620 Diff Adap.fact. OUT Diff err.: adverse Adaption factor CT
5631 Diff picked up OUT Differential protection picked up
5644 Diff 2.Harm L1 OUT Diff: Blocked by 2.Harmon. L1
5645 Diff 2.Harm L2 OUT Diff: Blocked by 2.Harmon. L2
5646 Diff 2.Harm L3 OUT Diff: Blocked by 2.Harmon. L3
5647 Diff n.Harm L1 OUT Diff: Blocked by n.Harmon. L1
5648 Diff n.Harm L2 OUT Diff: Blocked by n.Harmon. L2
5649 Diff n.Harm L3 OUT Diff: Blocked by n.Harmon. L3
5651 Diff Bl. exF.L1 OUT Diff. prot.: Blocked by ext. fault L1
5652 Diff Bl. exF.L2 OUT Diff. prot.: Blocked by ext. fault L2
5653 Diff Bl. exF.L3 OUT Diff. prot.: Blocked by ext. fault.L3
5657 DiffCrosBlk 2HM OUT Diff: Crossblock by 2.Harmonic
5658 DiffCrosBlk nHM OUT Diff: Crossblock by n.Harmonic
5660 DiffCrosBlk exF OUT Diff: Crossblock by ext. fault
5662 Block Iflt.L1 OUT Diff. prot.: Blocked by CT fault L1
5663 Block Iflt.L2 OUT Diff. prot.: Blocked by CT fault L2
5664 Block Iflt.L3 OUT Diff. prot.: Blocked by CT fault L3
5666 DiffStrtInChaL1 OUT Diff: Increase of char. phase (start) L1
5667 DiffStrtInChaL2 OUT Diff: Increase of char. phase (start) L2
5668 DiffStrtInChaL3 OUT Diff: Increase of char. phase (start) L3
5670 Diff I-Release OUT Diff: Curr-Release for Trip
5671 Diff TRIP OUT Differential protection TRIP
5672 Diff TRIP L1 OUT Differential protection: TRIP L1
5673 Diff TRIP L2 OUT Differential protection: TRIP L2
5674 Diff TRIP L3 OUT Differential protection: TRIP L3
5681 Diff> L1 OUT Diff. prot.: IDIFF> L1 (without Tdelay)
5682 Diff> L2 OUT Diff. prot.: IDIFF> L2 (without Tdelay)
5683 Diff> L3 OUT Diff. prot.: IDIFF> L3 (without Tdelay)
Addr. Parameter Setting Options Default Setting Comments
