A.1 Ordering Information and Accessories
499
7UT613/63x Manual
C53000-G1176-C160-2
A.1.1.2 Differential Protection 7UT633 and 7UT635 for 3 to 5 measuring locations
1)
One of the 2 voltage ranges can be selected with plug-in jumper
2)
For each binary input one of 2 pick-up threshold ranges can be selected with plug-in jumper
7 8 9 101112 131415
Differential Protec-
tion
7UT63 — — 0+ L/M
Inputs and outputs Housing, number of binary inputs and outputs
BI: Binary inputs, BO: Output relays
Pos. 6
12 current inputs (3 x 3–phase, + 3 x 1–phase)
4 voltage inputs (1 x 3–phase, +1 x 1–phase)
Housing
1
/
1
x19”,
21 BI, 24 BO, 1 live status contact
3
16 current inputs (5 x 3–phase, + 1 x 1–phase) or (4 x 3–phase, + 4 x 1–phase)
Housing
1
/
1
x 19”,
29 BI, 24 BO, 1 life contact
5
Equipment Pos. 7
Nominal current I
N
=1A 1
Nominal current I
N
=5A 5
Auxiliary voltage (power supply, pickup threshold of binary inputs) Pos. 8
DC 24 V to 48 V, binary input threshold 17 V
2)
2
60 to 125 VDC
1)
, binary input threshold 17 V
2)
4
110 to 250 VDC
1)
, 115 to 230 VAC, binary input threshold 73 V
2)
5
220 to 250 VDC
1)
, 115 to 230 VAC, binary input threshold 154 V
2)
6
Construction Pos. 9
Surface mounting housing with two-tier terminals B
Flush mounting housing with plug-in terminals D
In housing with screw terminals E
as B, with 5 relays as „High-speed Relays“ N
as D, with 5 relays as „High-speed Relays“ B
as E, with 5 relays as „High-speed Relays“ S
Region-specific default / language settings and function versions Pos. 10
Region world, German language (language can be changed) A
Region world, English language (GB) (language can be changed) B
Region world, American language (language can be changed) C
Region world, French language (language can be changed) D
Region world, Spanish language (language can be changed) E
