Siemens SIPROTEC 7UT613 series User Manual

2 Functions
330
7UT613/63x Manual
C53000-G1176-C160-2
2.23.1 Demand Measurement Setup
2.23.1.1 Setting Notes
Mean Value Forma-
tion
The synchronisation instant within one hour, the time interval and the time interval for
averaging can be set via parameters.
The selection of the time period for measured value averaging is set with parameter
7611 DMD Interval in the corresponding setting group from A to D under MEA-
SUREMENT. The first number specifies the averaging time window in minutes while
the second number gives the frequency of updates within the time window. 15 Min.,
3 Subs, for example, means: Time average is generated for all measured values with
a window of 15 minutes. The output is updated every 15/3 = 5 minutes.
Under address 7612 DMD Sync.Time it can be determined whether the point in time
for averaging selected under address 7611 is to commence on the hour (On The
Hour) or is to be synchronised with another point in time (15 After Hour, 30
After Hour or 45 After Hour).
If the settings for averaging are changed, then the measured values stored in the
buffer are deleted, and new results for the average calculation are only available after
the set time period has passed.
2.23.1.2 Settings
2.23.2 Min/Max Measurement Setup
2.23.2.1 Setting Notes
Resetting of the minimum and maximum values can also be done cyclically, com-
mencing with the preselected starting time. To select this feature, address 7621
MinMax cycRESET should be set to YES. The point in time when reset is to take place
(the minute of the day in which reset will take place) is set at address 7622 MiMa
RESET TIME. The reset cycle in days is entered at address 7623 MiMa
RESETCYCLE, and the beginning date of the cyclical process, from the time of the
setting procedure (in days), is entered at address 7624 MinMaxRES.START.
Addr. Parameter Setting Options Default Setting Comments
7611 DMD Interval 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
7612 DMD Sync.Time On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
