2.19 Monitoring Functions
287
7UT613/63x Manual
C53000-G1176-C160-2
2.19.1.6 Information List
8133A T Sym. I th. M3 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8141 BAL. I LIMIT M4 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 4
5A 0.50 .. 5.00 A 2.50 A
8142 BAL. FACT. I M4 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.4
8143A T Sym. I th. M4 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8151 BAL. I LIMIT M5 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor
Meas. Loc. 5
5A 0.50 .. 5.00 A 2.50 A
8152 BAL. FACT. I M5 0.10 .. 0.90 0.50 Bal. Factor for Curr.
Monitor Meas.Loc.5
8153A T Sym. I th. M5 5 .. 100 sec 5 sec Symmetry Iph: Pick-up
delay
8161 BALANCE U-LIMIT 10 .. 100 V 50 V Voltage Threshold for
Balance Monitoring
8162 BAL. FACTOR U 0.58 .. 0.90 0.75 Balance Factor for Voltage
Monitor
8163A T BAL. U LIMIT 5 .. 100 sec 5 sec T Balance Factor for
Voltage Monitor
No. Information Type of In-
formation
Comments
161 Fail I Superv. OUT Failure: General Current Supervision
163 Fail I balance OUT Failure: Current Balance
164 Fail U Superv. OUT Failure: General Voltage Supervision
165 Fail Σ U Ph-E OUT Failure: Voltage Summation Phase-Earth
167 Fail U balance OUT Failure: Voltage Balance
171 Fail Ph. Seq. OUT Failure: Phase Sequence
175 Fail Ph. Seq. I OUT Failure: Phase Sequence Current
176 Fail Ph. Seq. U OUT Failure: Phase Sequence Voltage
30110 Fail balan. IM1 OUT Fail.: Current Balance meas. location 1
30111 Fail balan. IM2 OUT Fail.: Current Balance meas. location 2
30112 Fail balan. IM3 OUT Fail.: Current Balance meas. location 3
30113 Fail balan. IM4 OUT Fail.: Current Balance meas. location 4
30114 Fail balan. IM5 OUT Fail.: Current Balance meas. location 5
30115 FailPh.Seq IM1 OUT Failure: Phase Sequence I meas. loc. 1
30116 FailPh.Seq IM2 OUT Failure: Phase Sequence I meas. loc. 2
30117 FailPh.Seq IM3 OUT Failure: Phase Sequence I meas. loc. 3
30118 FailPh.Seq IM4 OUT Failure: Phase Sequence I meas. loc. 4
30119 FailPh.Seq IM5 OUT Failure: Phase Sequence I meas. loc. 5
Addr. Parameter C Setting Options Default Setting Comments
