A Appendix
496
7UT613/63x Manual
C53000-G1176-C160-2
A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 Differential Protection 7UT613 for 3 Measuring Locations
1)
One of the 2 voltage ranges can be selected with plug-in jumper
2)
For each binary input one of 2 pick-up threshold ranges can be selected with plug-in jumper
7 8 9 101112 131415
Differential Protec-
tion
7UT613 — — 0+ L/M
Equipment Pos. 7
Nominal current I
N
=1A 1
Nominal current I
N
=5A 5
Auxiliary voltage (power supply, pickup threshold of binary inputs) Pos. 8
DC 24 V to 48 V, binary input threshold 17 V
2)
2
60 to 125 VDC
1)
, binary input threshold 17 V
2)
4
110 to 250 VDC
1)
, 115 to 230 VAC, binary input threshold 73 V
2)
5
220 to 250 VDC
1)
, 115 to 230 VAC, Binary Input Threshold 154 V
1) 2)
6
Construction: Housing, Number of Binary Inputs and Outputs
BI: Binary Inputs, BO: Output Relays
Pos. 9
Surface mounting housing with two-tier terminals,
1
/
2
x 19”, 5 BI, 8 BO, 1 live status contact B
Flush mounting housing,
1
/
2
x 19”, with plug-in terminals, 5 BI, 8 BO, 1 live status contact D
Flush mounting housing with screwed terminals,
1
/
2
x 19”, 5 BI, 8 BO, 1 live status contact E
Region-specific default / language settings and function versions Pos. 10
Region world, German language (language can be changed) A
Region world, English language (GB) (language can be changed) B
Region world, American language (language can be changed) C
Region world, French language (language can be changed) D
Region world, Spanish language (language can be changed) E
