Siemens SIPROTEC 7UT613 series User Manual

2 Functions
170
7UT613/63x Manual
C53000-G1176-C160-2
2021 Ip 1
A
0.10 .. 4.00 A 2.00 A Ip Pickup
5
A
0.50 .. 20.00 A 10.00 A
2022 Ip 0.10 .. 4.00 I/InS 2.00 I/InS Ip Pickup
2023 T Ip 0.05 .. 3.20 sec; ∞ 0.50 sec T Ip Time Dial
2024 D Ip 0.50 .. 15.00 ; ∞ 5.00 D Ip Time Dial
2025 TOC DROP-OUT Instantaneous
Disk Emulation
Disk Emulation TOC Drop-out characteristic
2026 IEC CURVE Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
2027 ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
2031 I/Ip PU T/Tp 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Pickup Curve I/Ip - TI/TIp
2032 MofPU Res T/Tp 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <-> TI/TIp
2041 2.HARM. Phase 10 .. 45 % 15 % 2nd harmonic O/C Ph. in % of fundamental
2042 I Max InRr. Ph. 1
A
0.30 .. 25.00 A 7.50 A Maximum Current for Inr. Rest. O/C Phase
5
A
1.50 .. 125.00 A 37.50 A
2043 I Max InRr. Ph. 0.30 .. 25.00 I/InS 7.50 I/InS Maximum Current for Inr. Rest. O/C Phase
2044 CROSS BLK.Phase NO
YES
NO CROSS BLOCK O/C Phase
2045 T CROSS BLK.Ph 0.00 .. 180.00 sec 0.00 sec CROSS BLOCK Time O/C Phase
2111 I>> 1
A
0.10 .. 35.00 A; ∞ 10.00 A I>> Pickup
5
A
0.50 .. 175.00 A; ∞ 50.00 A
2112 I>> 0.10 .. 35.00 I/InS; ∞ 10.00 I/InS I>> Pickup
2113 T I>> 0.00 .. 60.00 sec; ∞ 0.10 sec T I>> Time Delay
2114 I> 1
A
0.10 .. 35.00 A; ∞ 4.00 A I> Pickup
5
A
0.50 .. 175.00 A; ∞ 20.00 A
2115 I> 0.10 .. 35.00 I/InS; ∞ 4.00 I/InS I> Pickup
2116 T I> 0.00 .. 60.00 sec; ∞ 0.30 sec T I> Time Delay
Addr. Parameter C Setting Options Default Setting Comments
