A.9 Information List
583
7UT613/63x Manual
C53000-G1176-C160-2
- Lock Out: General TRIP (G-TRP
Quit)
P.System Data 2 IntSP * * * LED BO
- Error Systeminterface (SysIn-
tErr.)
Supervision IntSP ON
OFF
**LEDBO
- Error FMS FO 1 (Error FMS1) Supervision OUT ON
OFF
**LEDBO
- Error FMS FO 2 (Error FMS2) Supervision OUT ON
OFF
**LEDBO
- Disturbance CFC (Distur.CFC) Supervision OUT ON
OFF
**LEDBO
- Control Authority (Cntrl Auth) Cntrl Authority IntSP ON
OFF
*LED
- Control Authority (Cntrl Auth) Cntrl Authority DP ON
OFF
* LED 101 85 1 Yes
- Controlmode REMOTE (ModeR-
EMOTE)
Cntrl Authority IntSP ON
OFF
*LED
- Controlmode LOCAL (ModeLO-
CAL)
Cntrl Authority IntSP ON
OFF
*LED
- Controlmode LOCAL (ModeLO-
CAL)
Cntrl Authority DP ON
OFF
* LED 101 86 1 Yes
- circuit breaker Q0 (Q0) Control Device CF_D
12
on
off
BO
- circuit breaker Q0 (Q0) Control Device DP on
off
**BI CB
- Reset Minimum and Maximum
counter (ResMinMax)
Min/Max meter IntSP
_Ev
ON
- Threshold Value 1 (ThreshVal1) Thresh.-Switch IntSP ON
OFF
**LEDFC
TN
BO CB
- Reset meter (Meter res) Energy IntSP
_Ev
ON * BI
1 No Function configured (Not con-
figured)
Device SP
2 Function Not Available (Non Exis-
tent)
Device SP
3 >Synchronize Internal Real Time
Clock (>Time Synch)
Device SP_E
v
* * * LED BI BO 135 48 1 No
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Osc. Fault Rec. SP * * m LED BI BO 135 49 1 Yes
5 >Reset LED (>Reset LED) Device SP * * * LED BI BO 135 50 1 Yes
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO 135 51 1 Yes
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group SP * * * LED BI BO 135 52 1 Yes
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP ON
OFF
* LED BO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP ON
OFF
* LED BO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP ON
OFF
* LED BO
15 >Test mode (>Test mode) Device SP * * * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device SP * * * LED BI BO 135 54 1 Yes
022.2421 Time Overcurrent picked up
(Overcurrent PU)
General O/C OUT * ON
OFF
* LED BO 60 69 2 Yes
022.2451 Time Overcurrent TRIP (Overcur-
rentTRIP)
General O/C OUT * ON m LED BO 60 68 2 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
