2.22 Additional Functions
323
7UT613/63x Manual
C53000-G1176-C160-2
0 Pick-up thresh. 0.01 .. 17.00 P/SnS 1.10 P/SnS Pick-up threshold P-side
0 Pick-up thresh. 1A
5A
1.7 .. 3000.0 VAR
8.5 .. 15000.0 VAR
200.0 VAR
1000.0 VAR
Pick-up threshold Q meas. location
0 Pick-up thresh. 0.01 .. 17.00 Q/SnS 1.10 Q/SnS Pick-up threshold Q-side
0 P.U. THRESHOLD -0.99 .. 0.99 0.50 Pickup Threshold
0 T TRIP DELAY 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLOCKED BY FFM YES
NO
YES Block in case of Meas.-Voltage Loss
0A Blk I brkn cond YES
NO
YES Block for broken conductor in CT path
0A DROPOUT RATIO 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO 1.01 .. 3.00 1.05 Dropout Ratio
0 MEAS. QUANTITY I-Meas Loc/side
Curr. I1..I12
Curr. IZ1..IZ4
Voltage
P forward
P reverse
Q forward
Q reverse
Power factor
Frequency
I-Meas Loc/side Selection of Measured Quantity
0 Func. assigned Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 Function is applied to
0 Func. per phase IL1..IL3
IL1
IL2
IL3
3I0 (Zero seq.)
I1 (Pos. seq.)
I2 (Neg. seq.)
IL1..IL3 Function utilises component(s)
