3.3 Commissioning
387
7UT613/63x Manual
C53000-G1176-C160-2
„O/C Ph3 Not av.“ 209.2491 Time overcurrent protection for phase currents 3 is not available for
the configured protected object
2.1.42.1.6
„O/C Ph3 err Set“ 209.2493 Settings for time overcurrent protection for phase currents 3 not plau-
sible
2.4.2
O/C 3I0 not av. 1861 Time overcurrent protection for zero current is not available for the
configured protected object
2.1.4
„O/C 3I0 error“ 191.2493 Settings for time overcurrent protection for zero sequence current not
plausible
2.4.2
„O/C 3I0-2 n/a“ 321.2491 Time overcurrent protection for zero sequence current 2 is not avail-
able for the configured protected object
2.1.42.1.6
„O/C3I0-2 errSet“ 321.2493 Settings for time overcurrent protection 2 for zero sequence current
not plausible
2.4.2
„O/C 3I0-3 n/a“ 323.2491 Time overcurrent protection for zero sequence current 3 is not avail-
able for the configured protected object
2.1.42.1.6
„O/C3I0-3 errSet“ 323.2493 Settings for time overcurrent protection 3 for zero sequence current
not plausible
2.4.2
O/C 3I0 Err CT 1862 No assignment possible for time overcurrent protection for earth
current
2.1.4
„O/C E error“ 024.2493 Settings for time overcurrent protection for earth current not plausible 2.5
„O/C E2 ErrCT“ 325.2492 No assignment possible for time overcurrent protection for earth
current 2
2.1.42.1.6
„O/C E2 err. Set“ 325.2493 Settings for time overcurrent protection for earth current 2 not plausi-
ble
2.5
O/C1ph Err CT 5981 No assignment possible for single-phase time overcurrent protection 2.1.4
„O/C 1Ph err Set“ 200.2493 Settings for single-phase time overcurrent protection is not plausible 2.7
„I2 Not avail.“ 5172 Unbalanced load protection is not available for the configured pro-
tected object
2.1.4
„I2 Adap.fact.“ 5168 The matching factor of the current transformers for unbalanced load
protection is too great or too small
2.8
„I2 error set.“ 5180 Unbalanced load protection setting not plausible 2.8
O/L No Th.meas. 1545 Temperature reception for overload protection is missing (from RTD
box)
2.1.3
2.9.5
O/L not avail. 1549 Overload protection is not available for the configured protected
object
2.1.4
O/L Adapt.fact. 1546 The matching factor of the current transformers for overload protec-
tion is too great or too small
2.1.4
2.9
„O/L2 err. Set.“ 204.2493 Settings for overload protection 2 setting not plausible 2.9
„O/L2 No Th.meas“ 204.2609 Temperature reception for overload protection 2 is missing (from RTD
box)
2.9
„O/L2 Not avail.“ 204.2491 Overload protection 2 is not available for the configured protective
object
2.9
„O/L2 Adap.fact.“ 204.2494 The matching factor of the current transformers for overload protec-
tion 2 is too great or too small
2.9
„O/L set wrong“ 044.2493 Overload protection setting not plausible 2.9
„U/f Not avail.“ 5377 Overexcitation protection is not available for the configured protected
object
2.1.4
„U/f Err No VT“ 5376 Overexcitation protection is not available without voltage connection 2.1.4
„U/f err. Set.“ 5378 Overexcitation protection setting not plausible 2.11
„U< err. Obj.“ 033.2491 Undervoltage protection is not available for the configured protected
object
2.14
Message No Meaning see
Section
