Siemens SIPROTEC 7UT613 series User Manual

4 Technical Data
482
7UT613/63x Manual
C53000-G1176-C160-2
General Limits
MV_GET_STATUS Information status mea-
sured value, decoder
XX X X
MV_SET_STATUS Measured value with status,
encoder
XX X X
NAND NAND - Gate X X X X
NEG Negator X X X X
NOR NOR - Gate X X X X
OR OR - Gate X X X X
REAL_TO_DINT Real after DoubleInt,
adapter
XX X X
REAL_TO_UINT Real after U-Int, adapter X X X X
RISE_DETECT Rising edge detector X X X X
RS_FF RS- Flipflop – X X X
RS_FF_MEMO Status memory for restart X X X X
SI_GET_STATUS Information status single
point indication, decoder
XX X X
SI_SET_STATUS Single point indication with
status, encoder
XX X X
SQUARE_ROOT Root Extractor X X X X
SR_FF SR- Flipflop – X X X
SR_FF_MEMO Status memory for restart X X X X
ST_AND AND gate with status X X X X
ST_NOT Negator with status X X X X
ST_OR OR gate with status X X X X
SUB Substraction X X X X
TIMER Timer – X X –
TIMER_SHORT Simple timer – X X –
UINT_TO_REAL U-Int to real, adapter X X X X
UPPER_SETPOINT Upper Limit X – – –
X_OR XOR - Gate X X X X
ZERO_POINT Zero Supression X – – –
Designation Limit Comments
Maximum number of all CFC charts
considering all task levels
32 When the limit is exceeded, an error
message is output by the device. Conse-
quently, the device is put into monitoring
mode. The red ERROR-LED lights up.
Maximum number of all CFC charts
considering one task level
16 Only Error Message
(record in device fault log, evolving fault in
processing procedure)
Maximum number of all CFC inputs
considering all charts
400 When the limit is exceeded, an error
message is output by the device. Conse-
quently, the device is put into monitoring
mode. The red ERROR-LED lights up.
