A.8 Settings
577
7UT613/63x Manual
C53000-G1176-C160-2
7622 MiMa RESET TIME Min/Max meter 0 .. 1439 min 0 min MinMax Reset Timer
7623 MiMa RESETCYCLE Min/Max meter 1 .. 365 Days 7 Days MinMax Reset Cycle Period
7624 MinMaxRES.START Min/Max meter 1 .. 365 Days 1 Days MinMax Start Reset Cycle in
8101 BALANCE I Measurem.Superv ON
OFF
OFF Current Balance Supervision
8102 BALANCE U Measurem.Superv ON
OFF
OFF Voltage Balance Supervision
8104 SUMMATION U Measurem.Superv ON
OFF
OFF Voltage Summation Supervision
8105 PHASE ROTAT. I Measurem.Superv ON
OFF
OFF Current Phase Rotation Supervi-
sion
8106 PHASE ROTAT. U Measurem.Superv ON
OFF
OFF Voltage Phase Rotation Supervi-
sion
8111 BAL. I LIMIT M1 Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor Meas.
Loc. 1
5A 0.50 .. 5.00 A 2.50 A
8112 BAL. FACT. I M1 Measurem.Superv 0.10 .. 0.90 0.50 Bal. Factor for Curr. Monitor
Meas.Loc.1
8113A T Sym. I th. M1 Measurem.Superv 5 .. 100 sec 5 sec Symmetry Iph: Pick-up delay
8121 BAL. I LIMIT M2 Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor Meas.
Loc. 2
5A 0.50 .. 5.00 A 2.50 A
8122 BAL. FACT. I M2 Measurem.Superv 0.10 .. 0.90 0.50 Bal. Factor for Curr. Monitor
Meas.Loc.2
8123A T Sym. I th. M2 Measurem.Superv 5 .. 100 sec 5 sec Symmetry Iph: Pick-up delay
8131 BAL. I LIMIT M3 Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor Meas.
Loc. 3
5A 0.50 .. 5.00 A 2.50 A
8132 BAL. FACT. I M3 Measurem.Superv 0.10 .. 0.90 0.50 Bal. Factor for Curr. Monitor
Meas.Loc.3
8133A T Sym. I th. M3 Measurem.Superv 5 .. 100 sec 5 sec Symmetry Iph: Pick-up delay
8141 BAL. I LIMIT M4 Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor Meas.
Loc. 4
5A 0.50 .. 5.00 A 2.50 A
8142 BAL. FACT. I M4 Measurem.Superv 0.10 .. 0.90 0.50 Bal. Factor for Curr. Monitor
Meas.Loc.4
8143A T Sym. I th. M4 Measurem.Superv 5 .. 100 sec 5 sec Symmetry Iph: Pick-up delay
8151 BAL. I LIMIT M5 Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Balance Monitor Meas.
Loc. 5
5A 0.50 .. 5.00 A 2.50 A
8152 BAL. FACT. I M5 Measurem.Superv 0.10 .. 0.90 0.50 Bal. Factor for Curr. Monitor
Meas.Loc.5
8153A T Sym. I th. M5 Measurem.Superv 5 .. 100 sec 5 sec Symmetry Iph: Pick-up delay
8161 BALANCE U-LIMIT Measurem.Superv 10 .. 100 V 50 V Voltage Threshold for Balance
Monitoring
8162 BAL. FACTOR U Measurem.Superv 0.58 .. 0.90 0.75 Balance Factor for Voltage
Monitor
8163A T BAL. U LIMIT Measurem.Superv 5 .. 100 sec 5 sec T Balance Factor for Voltage
Monitor
8201 TRIP Cir. SUP. TripCirc.Superv ON
OFF
OFF TRIP Circuit Supervision
8401 BROKEN WIRE Supervision OFF
ON
OFF Fast broken current-wire supervi-
sion
8403 FUSE FAIL MON. Supervision OFF
ON
OFF Fuse Failure Monitor
8422A FFM I< M1 Supervision 1A 0.04 .. 2.00 A 0.10 A I< for FFM detection M1
5A 0.20 .. 10.00 A 0.50 A
8423A FFM I< M2 Supervision 1A 0.04 .. 2.00 A 0.10 A I< for FFM detection M2
5A 0.20 .. 10.00 A 0.50 A
8424A FFM I< M3 Supervision 1A 0.04 .. 2.00 A 0.10 A I< for FFM detection M3
5A 0.20 .. 10.00 A 0.50 A
8426A FFM U<max (3ph) Supervision 2 .. 100 V 5 V Maximum Voltage Threshold U<
(3phase)
8601 EXTERN TRIP 1 External Trips OFF
ON
Block relay
OFF External Trip Function 1
Addr. Parameter Function C Setting Options Default Setting Comments
