Diagnostics
5.2 Diagnostics using LEDs
Commissioning with Startdrive
Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
143
State
Description, cause
Remedy
Ready
DC link
Green / red
flashing light
0.5 Hz
– Firmware is being downloaded. –
Green / red
flashing light
2 Hz
– Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green /
orange
or
Red / orange
– Component detection via LED is activated (p0124).
Note:
Both options depend on the LED status when module recog-
nition is activated via p0124 = 1.
–
5.2.2.3
Basic Line Module booksize
Table 5- 6 Meaning of the LEDs on the Basic Line Module
State
Description, cause
Remedy
Ready
DC link
Off Off Electronic power supply is missing or outside permissible
tolerance range.
–
Green Off The component is ready for operation and cyclic DRIVE-CLiQ
communication is taking place.
–
Orange The component is ready for operation and cyclic DRIVE-CLiQ
communication is taking place.
The DC link voltage is present.
–
Red The component is ready for operation and cyclic DRIVE-CLiQ
communication is taking place.
The DC link voltage is too high.
Check the line voltage.
Orange
Orange
DRIVE-CLiQ communication is being established.
–
Red – At least one fault is present in this component.
Note:
LED is controlled irrespective of the corresponding messages
being reconfigured.
Remedy and acknowledge
fault.
Green / red
flashing light
0.5 Hz
– Firmware is being downloaded. –
Green / red
flashing light
2 Hz
– Firmware download is complete. Wait for POWER ON. Carry out a POWER ON
Green /
orange
or
Red / orange
flashing light
– Component detection via LED is activated (p0124).
Note:
Both options depend on the LED status when module recog-
nition is activated via p0124 = 1.
–
