Diagnostics
5.3 Diagnostics via Startdrive
Commissioning with Startdrive
Commissioning Manual, (IH3), 07/2016, 6SL3097-4AA10-0BP0
163
Trigger condition: Trigger on alarm
1. In order to record a time period before the trigger event, enter a value greater than 0 in
the input field for the pre-trigger.
2. Enter the recording time under "Recording duration". The possible total duration is
displayed to the right.
Activate the option "Recording duration = max. recording duration" if you wish to set the
total duration.
3. Enter a recording cycle under "Cycle" The possible cycle settings depend on the number
of signals.
Additional information on handling the trace function and the configuration and evaluation of
the trace is provided in the Startdrive online help.
Transferring the trace configuration to the device
Requirement
● A valid trace configuration is provided in the "Traces" system folder.
● The maximum number of traces has still not been reached.
Proceed as follows to transfer a trace configuration to the drive:
1. Open a valid trace configuration in the working area.
2. Click on icon
.
The "Go online" dialog is displayed if an online connection to the drive has not been
active up until now.
Here, make the settings for the online connection (also see Chapter "Establishing an
online connection to the drive (Page 90)") and click on "Connect".
The trace configuration is transferred to the drive.
