Configuration
6.2 Configuring the busbar run layout
SIVACON 8PS - Configuring with LX system
112 Configuration Manual, 10/2011, A5E02194899-02
Feeder unit of non-Siemens distribution boards via non-Siemens distribution board
connection units (FA)
/
① Junction unit
② Busbar connection units for non-Siemens distribution boards (FA)
③ Non-Siemens distribution boards
④ Last trunking unit before the non-Siemens distribution board connection unit
⑤ Front view of non-Siemens distribution board
⑥ Fixed point (here: LX-BHF).
A fixed point must be attached in the immediate vicinity of each of the feeder
units (
② and ⑥).
