Configuration
6.2 Configuring the busbar run layout
SIVACON 8PS - Configuring with LX system
122 Configuration Manual, 10/2011, A5E02194899-02
Parts list for configuring example
Item
no.
Type Max. rated current
[A]
Designation Number
1 LXA0551-FA 1600 Connection unit for non-Siemens distribution
boards
1
2 LXA0551-D 1600 Expansion compensation unit 1
3 LXA0551-2W1.40
+ LXA0551-S120-X0.95
1600 Straight trunking unit (optional length 1.4 m) with
fire barrier
11
4 LXA0551-1W2.0-1AD1.40 1600 Straight trunking unit with 1 tap-off point (optional
length 2 m with optional tap-off point at 1.4 m)
11
5 LXA0551-EF — End cap 1
6 LX-BHF — Fixed point (edgewise busbars) 1
7 LXA07-BV1-AK — Vertical fixing bracket for power distribution 11
8 LX-AK5/FSH250-IEC-3S 200 Tap-off unit with fuse switch disconnector, IEC 3-
pole
15
See also
Planning expansion compensation and fixed point (Page 109)
Fire barrier (Page 106)
