SDM3055 Series Digital Multimeter User Manual

14 int.siglent.com

Back Panel

SDM3055 Digital Multimeter’s Back Panel provides users with abundant interfaces, including USB

Device, USB Host, LAN and GPIB (Only for SDM3055A), as shown in the following diagram.

Diagram 1-5 Back Panel Overview

Power Socket

10/100 Ethernet

Power Fuse

VMC Output

AC Voltage Selector

Ext Trig

Inspection card interface

Current Input Fuse

USB Device (USBTMC)
