SDM3055 Series Digital Multimeter User Manual
int.siglent.com 33
To Measure 2-Wire/4-Wire Resistance
The Multimeter enables to measure 2-Wire Resistance and 4-Wire Resistance. The method to
connect and measure 2-Wire/4-Wire Resistance will be introduced in details separately.
2-Wire Resistance
Operating Steps:
1. Press on the front panel to enter the 2-Wire Resistance measurement interface, as shown
in Diagram 2- 13.
Diagram 2-13 2-Wire Resistance Measurement Interface
2. Connect the red lead to terminal Input-HI and black lead to terminal Input-LO as the following
diagram.
Diagram 2-14 Sketch Map for Measuring 2-Wire Resistance
To Next Page
