SDM3055 Series Digital Multimeter User Manual
int.siglent.com 27
To Measure DC Current
The Multimeter enables to measure DC Current up to 10A. The method to connect and measure DC
Current will be introduced in details as the following steps.
Operating Steps:
1. Press and on the front panel to enter the DC Current measurement interface, as
shown in Diagram 2- 6.
Diagram 2-6 DC Current Measurement Interface
2. Connect the red lead to terminal Input-I and black lead to terminal Input-LO as the following
diagram.
Diagram 2-7 Sketch Map for Measuring DC Current
3. Choose a proper current range according to the measured circuit.
To Next Page
