SIGLENT TECHNOLOGIES SDM3055 Series User Manual

SDM3055 Series Digital Multimeter User Manual
74 int.siglent.com
Table 2-22 Statistic Measurement Menu Function Description
Function Menu
Settings
Description
Statistics
Show/Hide
Show or hide the statistics function interface.
Min
Show the minimum statistics value of current measurement.
Average
Show the average statistics value of current measurement.
Max
Show the maximum statistics value of current measurement.
Span
Show the span of current measurement.
Std dev
Show the std dev statistics value of current measurement.
Samples
Show the maximum statistics value of current measurement.
Clear Readings
Clear all current readings and restart statistics.
Done
Return to the higher-level menu.
Statistics Function:
⚫ In statistic function, the first reading is usually set to the maximum or minimum value. When
getting more readings, current displaying value is always the maximum/minimum reading among
all the measured values.
⚫ The maximum, minimum, average and reading quantities are stored in volatile memory.
Limits
Limits function is available to prompt signals beyond ranges according to the upper and lower
parameters. Following are some measurement functions which are able to do limit operation: DC
Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Period, Capacitance and
Temperature.
Press → [Limits] → [On] to enter the interface shown in the following diagram.
Diagram 2-59 Limits
