SDM3055 Series Digital Multimeter User Manual
32 int.siglent.com
Table 2-4 Measurement Characteristics of AC Current
Ranges*
200μA , 2mA , 20mA , 200mA , 2A , 10A
Input Protection
10A(back panel), 250V(fuse), 12A(inside the instrument)
Configurable
Range, Rel
NOTE*:
All the ranges enable to obtain 20% value higher than original except 10A. Besides, both Manual
and Auto are available for setting every range.
4. Set relative value (Optional operation).
Press [Rel] to open or close Relative math function. When it is opened, the reading displayed is
a relative value which comes from the result of actual measurement value subtracts the value
that has been set. (Please refer to “Math Functions” in Chapter 2 to know about the details.)
5. Read measurement result.
Select required measurement rate (reading rate) by pressing [Speed] and read the measurement
result.
6. View history data.
There are four types of way to view historical data: “Number”, “Bar Meter” “Trend Chart” and
“Histogram”.
