2nF , 20nF , 200nF , 2μF , 200μF , 200μF , 10000μF
NOTE*:
All the ranges enable to obtain 20% value higher than original. Besides, both Manual and Auto
are available for setting every range.
4. Set relative value (Optional operation).
Press [Rel] to open or close Relative math function. When it is opened, the reading displayed is
a relative value which comes from the result of actual measurement value subtracts the value
that has been set. (Please refer to “Math Functions” in Chapter 2 to know about the details.)
5. Read measurement result.
Capacitance measurement is fixed at “Slow” rate. Therefore, you can’t adjust the reading rate
when reading the result.
6. View history data.
There are four types of way to view historical data: “Number”, “Bar Meter” “Trend Chart” and
“Histogram”.
NOTE:
Before measuring the electrolytic capacitance, you should make the two legs of the electrolytic
capacitance short circuit and let it be discharged.
