3. Set the Short-circuit resistance.
The default value is set as 50Ω before leaving factory. The value can be changed by using
direction keys. You also can execute the Continuity measurement directly without modification.
Table 2-10 Measurement Characteristics of Continuity
Test Current
1mA
Ranges*
Fixed at 2kΩ
Open-circuit Voltage
<8V
Input Protection
1000V on all ranges (HI terminal)
Beep Condition
0 ≤ Rtesting ≤ Short-circuit impedance
1Ω ≤ Short-circuit impedance ≤ 2kΩ
4. Set the Beeper function.
Press [Beeper] to turn on or off the Beeper. If the circuit is continuous, the instrument will beep
once when the Beeper is turned on.
5. Search for the test point and read measurement result.
NOTE:
Before testing continuity, please cut off the power and discharge all the high-voltage containers to
avoid damages to the Multimeter.
