Table 2-11 Characteristics of Checking Diodes
Test Current
1mA
Ranges*
Fixed at 2V
Open-circuit Voltage
<8V
Input Protection
1000V (HI terminal)
Beep Condition
0.1V≤V measured ≤ 2.0V
4. Read measurement result.
5. Reverse the probes and measure the voltage in the diode once more. Evaluate the diode
according to the following rules:
⚫ If the Multimeter shows “overload” when in reverse bias model, it indicates that the diode is
normal.
⚫ If the Multimeter shows voltage about 0V and the instrument beeps persistently when in
forward and reverse bias model, it indicates that the diode is short.
⚫ If the Multimeter shows “overload” when in forward and reverse model, it indicates that the
diode is open.
NOTE:
Before testing diode, please cut off the power and discharge all the high-voltage containers to avoid
damages to the Multimeter.
