SDM3055 Series Digital Multimeter User Manual
int.siglent.com 59
2. Choose the file location.
Press [Browse] and use direction keys to select the corresponding file.
3. Press [File Name] to enter the following interface.
Diagram 2-44 Input File Name
The method of inputting file name:
⚫ Press direction keys to select a desired char in the input area.
⚫ Press “OK” key on the front panel to input selected char in the input area.
⚫ Press [Clear All] to clear all input chars.
⚫ Press [Delete Char] to delete the letter on which the cursor taking place.
⚫ Press [Previous Char] to move the cursor in the file name area to the previous char.
⚫ Press [Next Char] to move the cursor in the file name area to the next char.
⚫ Press [Done] to save the current file and return to the higher-level menu.
⚫ Press [Cancel] to cancel the current operation and return to the higher-level menu.
4. Press [Action] and select [Folder], [Capture Display], [Copy], [Rename] or [Delete] to do the
corresponding operation.
Table 2-15 Action Settings
Function Menu
Description
Folder
Press [Create Folder] to create a new folder.
Capture
Display
Press [Save Screen] to save current captured screen picture as
standard BMP format.
Copy
Press [Perform Copy] to copy the selected file.
Rename
Press [Perform Rename] to rename the selected file.
Delete
Press [Perform Delete] to delete the selected file.
Done
Save all changes and return to the higher-level menu.
