Document: LT0400 4100U-S1 Programming Guide
Issue 1.4 15 December 2010 Page v
6.3.6 4090-9118 RELAY IAM WITH T-SENSE INPUT 6-4
6.3.7 4090-9119 RELAY IAM WITH UNSUPERVISED INPUT 6-5
6.3.8 4090-9120AU 6 POINT I/O MODULE (4 INPUTS, 2 RELAY OUTPUTS) 6-5
6.3.9 4090-9116 ADDRESSABLE IDNET ISOLATOR 6-6
6.3.10 4090-9117AU ADDRESSABLE IDNET POWER ISOLATOR 6-6
6.4 IDNET DEVICES TYPICAL APPLICATIONS 6-7
7 ADDING ZONE DISPLAYS 7-1
7.1 GENERAL 7-2
7.2 ZONE CONTROL AND LED MODULES 7-2
7.3 HARDWARE CONFIGURATION MODIFICATION 7-2
7.4 MODIFY THE CUSTOM CONTROL EQUATIONS FOR THE ZONES 7-6
8 ADDING EXPANSION MODULES 8-1
8.1 GENERAL 8-2
8.2 ADDING 4100-3101 IDNET LOOP CARD 8-2
8.3 ADDING 4100-4321 LEGACY SIGNAL CARD 8-5
8.4 ADDING 4100-5004 8 POINT MONITOR CARD. 8-7
8.5 ADDING 4100-3003 8 AUX RELAY CARD. 8-8
8.6 ADDING 4100-0302/1290 24 POINT GRAPHIC INTERFACE. 8-9
8.7 ADDING LEGACY CARD – 4100-0113 RS-232/2120 INTERFACE MODULE 8-10
8.7.1 TYPICAL PRINTER CONFIGURATION: 8-11
9 CUSTOM CONTROL 9-1
9.1 GENERAL 9-2
9.2 CUSTOM CONTROL SYNTAX 9-2
9.3 CREATING A NEW EQUATION 9-4
9.3.1 SELECT USER PROGRAM 9-4
9.3.2 ADD INPUT STATEMENTS 9-5
9.3.3 ADD OUTPUT STATEMENTS 9-6
9.3.4 OUTPUT STATEMENTS: HOLD VS. TRACK 9-7
10 AS1668 FAN CONTROLS 10-1
10.1 TYPICAL ARRANGEMENT FOR AS1668 FAN CONTROL 10-2
10.2 AS1668 FAN CONTROL FLOWS 10-3
10.3 AS1668 FAN CONTROL STATE TABLE 10-5
10.4 AS1668 FAN CONTROL CARD PROGRAMMING 10-6
10.4.1 SWITCH CONFIGURATION 10-6
10.4.2 LED CONFIGURATION 10-7
10.4.3 POINT EDITING 10-8
10.5 AS1668 CUSTOM CONTROL EQUATIONS 10-9
10.5.1 FAN FAULT AND S/A RESTART DELAYS-STARTUP 10-9
10.5.2 SET UP REGISTER 8 10-10
10.5.3 S/A DETECTOR ISOLATE 10-10
10.5.4 S/A DETECTOR DE-ISOLATE 10-10
10.5.5 S/A DETECTOR ACTIVE 10-11
10.5.6 TRIGGER FAN ON 10-11
10.5.7 TRIGGER FAN OFF 10-11
10.5.8 FAN FAULT CONDITIONS 10-12
