Simplex 4100U Application Guide

5-1
This chapter provides examples of Simplex Smoke Control System programs. These programs are
presented to illustrate what can be accomplished with this system. Since every system is unique,
your programs will not be identical to these programs. Instead, use these programs as templates
when programming the system.
Keep in mind the following smoke control objectives when programming the system:
• Maintain safe fire-free and smoke-free routes to allow sufficient time for the occupants to exit
the premises or move to designated safe refuge areas.
• Provide a relatively clear approach to the fire area by firefighters so that the fire (the source of
the smoke) can be contained and extinguished as fast as possible.
• If designated safe refuge areas are a part of the life safety design, then the control system must
prevent smoke migration into such areas for a prolonged period of time.
• Reduce the amount of fire and smoke damage to the property.
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Smoke Control Program Requirements 5-2
Dedicated Smoke Control System Weekly Self-Test 5-3
Smoke Control System Custom Control Equations 5-5
Chapter 5
Smoke Control System Programs
Introduction
In this Chapter

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
