Simplex 4100U Application Guide

5-18
Label: REPORT TBL IF SUP DAMPER 1 NOT OPEN Equation 31
COMMENTS:
INPUTS:
The ON state of:
M1-15 CDAMPER 1ST FLOOR SUPPLY AIR DAMPER
DELAY for 10 sec., running timer is A257
AND NOT the ON state of:
M1-25 UTILITY MONITOR FLR 1 SUPPLY AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P260 UTILITY FL1 SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF SUP DAMPER 1 NOT CLOSED Equation 32
COMMENTS:
INPUTS:
NOT the ON state of:
M1-15 CDAMPER 1ST FLOOR SUPPLY AIR DAMPER
DELAY for 10 sec., running timer is A282
AND NOT the ON state of:
M1-29 UTILITY MONITOR FLR 1 SUPPLY AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P260 UTILITY FL1 SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF SUP DAMPER 2 NOT OPEN Equation 33
COMMENTS:
INPUTS:
The ON state of:
M1-16 CDAMPER 2ND FLOOR SUPPLY AIR DAMPER
DELAY for 10 sec., running timer is A270
AND NOT the ON state of:
M1-26 UTILITY MONITOR FLR 2 SUPPLY AIR DAMPER OPEN
OUTPUTS:
HOLD points ON pri=9,9
P261 UTILITY FL2 SUPPLY AIR DAMPER FAIL
END:
Label: REPORT TBL IF SUP DAMPER 2 NOT CLOSED Equation 34
COMMENTS:
INPUTS:
NOT the ON state of:
M1-16 CDAMPER 2ND FLOOR SUPPLY AIR DAMPER
DELAY for 10 sec., running timer is A271
AND NOT the ON state of:
M1-30 UTILITY MONITOR FLR 2 SUPPLY AIR DAMPER CLOSED
OUTPUTS:
HOLD points ON pri=9,9
P261 UTILITY FL2 SUPPLY AIR DAMPER FAIL
END:
Smoke Control System Custom Control Equations, Continued
Equation 31:
Report TBL If SUP
Damper 1 Not Open
Equation 32:
Report TBL If
SUP Damper 1
Not Closed
Equation 33:
Report TBL If SUP
Damper 2 Not Open
Equation 34:
Report TBL If
Sup Damper 2
Not Closed
