Simplex 4100U Application Guide

5-29
Label: MANUAL CONTROL CLEAR FAULTS Equation 75
COMMENTS:
INPUTS:
The UP state of:
8-80 SWITCH Ann 1 Pt 80 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=9,9
P260 UTILITY FL1 SUPPLY AIR DAMPER FAIL
P261 UTILITY FL2 SUPPLY AIR DAMPER FAIL
P262 UTILITY FL3 SUPPLY AIR DAMPER FAIL
P263 UTILITY FL4 SUPPLY AIR DAMPER FAIL
P264 UTILITY FL1 EXHAUST AIR DAMPER FAIL
P265 UTILITY FL2 EXHAUST AIR DAMPER FAIL
P266 UTILITY FL3 EXHAUST AIR DAMPER FAIL
P267 UTILITY FL4 EXHAUST AIR DAMPER FAIL
P268 UTILITY MAIN SUPPLY FAN FAIL
P269 UTILITY MAIN EXHAUST FAN FAIL
P270 UTILITY MAIN RETURN AIR DAMPER FAIL
P271 UTILITY MAIN SUPPLY AIR DAMPER FAIL
P272 UTILITY MAIN EXHAUST AIR DAMPER FAIL
P280 UTILITY STAIR PRESS FAN FAIL
END:
Label: MASTER KEY SWITCH Equation 76
COMMENTS:
INPUTS:
The UP state of:
8-81 SWITCH Ann 1 Pt 81 Graphic LED/SW Ctlr w/32
OUTPUTS:
TRACK points ON pri=8,9
P273 UTILITY MASTER KEY SWITCH ENABLE
END:
Smoke Control System Custom Control Equations, Continued
Equation 75:
Manual Control
Clear Faults
Equation 76:
Master Key-Switch

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
