Simplex 4100U Application Guide

5-22
Label: MANUAL CONTROL SUP AIR DAMPER 1 OPEN Equation 47
COMMENTS:
INPUTS:
The UP state of:
8-66 SWITCH Ann 1 Pt 66 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-15 CDAMPER 1ST FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 1 CLOSE Equation 48
COMMENTS:
INPUTS:
The DOWN state of:
8-66 SWITCH Ann 1 Pt 66 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-15 CDAMPER 1ST FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 2 OPEN Equation 49
COMMENTS:
INPUTS:
The UP state of:
8-68 SWITCH Ann 1 Pt 68 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=5,9
M1-16 CDAMPER 2ND FLOOR SUPPLY AIR DAMPER
END:
Label: MANUAL CONTROL SUP AIR DAMPER 2 CLOSE Equation 50
COMMENTS:
INPUTS:
The DOWN state of:
8-68 SWITCH Ann 1 Pt 68 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=5,9
M1-16 CDAMPER 2ND FLOOR SUPPLY AIR DAMPER
END:
Smoke Control System Custom Control Equations, Continued
Equation 47:
Manual Control SUP
AIR Damper 1 Open
Equation 48:
Manual Control SUP
Air Damper 1 Close
Equation 49:
Manual Control SUP
Air Damper 2 Open
Equation 50:
Manual Control SUP
Air Damper 2 Close

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
