Simplex 4100U Application Guide

5-27
Label: MANUAL CONTROL MAIN RET AIR DAMPER OPEN Equation 67
COMMENTS:
INPUTS:
The UP state of:
8-75 SWITCH Ann 1 Pt 75 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=8,9
M1-14 CDAMPER MAIN RETURN AIR DAMPER
END:
Label: MANUAL CONTROL MAIN RET AIR DAMPER CLOSE Equation 68
COMMENTS:
INPUTS:
The DOWN state of:
8-75 SWITCH Ann 1 Pt 75 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=8,9
M1-14 CDAMPER MAIN RETURN AIR DAMPER
END:
Label: MANUAL CONTROL MAIN EXHAUST FAN ON Equation 69
COMMENTS:
INPUTS:
The UP state of:
8-76 SWITCH Ann 1 Pt 76 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points ON pri=8,9
M1-11 CPRESS EXHAUST FAN RELAY
END:
Label: MANUAL CONTROL MAIN EXHAUST FAN OFF Equation 70
COMMENTS:
INPUTS:
The DOWN state of:
8-76 SWITCH Ann 1 Pt 76 Graphic LED/SW Ctlr w/32
AND the ON state of:
P273 UTILITY MASTER KEY SWITCH ENABLE
OUTPUTS:
HOLD points OFF pri=8,9
M1-11 CPRESS EXHAUST FAN RELAY
END:
Smoke Control System Custom Control Equations, Continued
Equation 67:
Manual Control
Main RET Air
Damper Open
Equation 68:
Manual Control
Main RET Air
Damper Close
Equation 69:
Manual Control Main
Exhaust Fan ON
Equation 70:
Manual Control Main
Exhaust Fan OFF

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
